Today’s engineers are faced with the need to develop filters that satisfy increasingly harsh operating conditions and simple processing requirements. Master Bond has recently introduced an advanced line of compounds for the range of bonding applications in the assembly of filters. This line includes adhesive technologies meant to handle applications ranging from filter media sealing to end cap potting and general filter assembly.
.jpg)
Chemical and Temperature Resistance
Master Bond’s one and two part epoxies are specially formulated for performance in a range of operating conditions. Master Bond filter assembly adhesives possess superior chemical resistance and heat resistance for those applications in constant exposure to abrasives and high heat. Formulations are available that have excellent long-term resistance to gasoline, kerosene, alcohols, and other fuels and lubricants. They also offer outstanding resistance to crude oils and its derivatives, natural gas and gaseous fuels. Special grades offer high dimensional stability, superior abrasion resistance, underwater curing capability, and exceptional adhesion to steel, aluminum alloys, copper, and other metals.
High Reliability and Performance
Master Bond's systems are designed to offer superior quality and long-term durability. They have earned a well-deserved reputation for their performance upon exposure to hostile environmental conditions. Select from a wide range of systems conveniently packaged for ease of use. These compounds are available in different viscosities, cure times, chemical resistances, electrical properties, colors, etc. to best meet specific requirements. They are presently employed in applications ranging from design and production to repair, maintenance and field service.
Key Benefits of Master Bond in Filter Applications
Some key benefits of Master Bond in filter applications are listed below:
- Solvent-free systems
- Rapid curing
- Withstand high pressure
- Flame retardancy- meet UL 94V-0 specifications
- Low outgassing
- FDA compliance- CFR 175.300 & CFR 175.105
- High bond strength
- Chemical resistant
- High and low viscosities
- Flexibility & toughness
- Vibration, shock and impact resistant
- High Tg
.jpg)
Industrial Applications
Some industrial applications of the adhesives are:
- Pharmaceutical
- Transportation
- Oil and chemical processing
- Medical devices
- Food
Other Applications
Other applications of Master Bond epoxies are listed below:
- Air and gas filtration
- Liquid filtration
- Chemical and fluid filters
- Reverse osmosis filters
Master Bond Polymer System Supreme 10HT for Filter Applications
Master Bond Polymer System Supreme 10HT features a unique blend of performance properties for filter applications, including both high shear and peel strengths and is a convenient non-drip system. This one component system is formulated to cure at elevated temperatures, e.g. 1 hour at 250°F, shorter times at higher temperatures. Tensile shear strengths in excess of 3,600 psi and T-peel strengths in excess of 30 pli are readily obtained.
Master Bond Supreme 10HT forms high-strength bonds for service over the remarkably wide temperature range of -320°F to over 400°F. In fact, it has been used successfully in cryogenic applications down to 4K. As a toughened system, it offers superior resistance to impact, thermal shock, vibration and stress fatigue cracking while maintaining the moisture, creep, corrosion and thermal resistance typical of epoxy resins. It is 100% reactive and does not contain any diluents or solvents.
Master Bond Polymer System Supreme 10HT is remarkably resistant to severe thermal cycling and many chemicals including water, oil, fuels and most organic solvents even upon prolonged exposures. Adhesion to metals, glass, ceramics, wood, vulcanized rubbers and many plastics is excellent. The cured epoxy is a superior electrical insulator.
Packaging
Master Bond Inc. offers a wide selection of different packaging solutions to best meet specific application requirements. They are designed to optimize dispensing of Master Bond compounds. Master Bond's innovative packaging solutions will maximize productivity, reduce waste and maintain consistently high product reliability. Packaging options are available for epoxies, polyurethanes, polysulfides, silicones, acrylics and UV cure systems. Additionally, special packaging is available for anaerobics, cyanoacrylates, latex systems and other resin formulations
.jpg)
This information has been sourced, reviewed and adapted from materials provided by Master Bond Inc.
For more information on this source, please visit Master Bond Inc.
