Electrically Insulative High Performance Epoxy Adhesive System EP13

Topics Covered

Introduction
Cutting Edge Formulations
Outstanding Technical Support
Latest Technological Advancements
About Master Bond

Introduction

Master Bond EP13 combines strength and heat resistance into an easy to use, one part system. As a single component system, its working life is indefinite at room temperature and it does not require any mixing prior to use. This system is formulated to cure readily in just 60-90 minutes at temperatures from 300-350°F.


EP13 is a paste and can be conveniently applied with a spatula, knife, trowel, and brush or paint roller, even to vertical surfaces without sagging or dripping. EP13 forms rigid and dimensionally stable bonds that readily attain tensile shear strengths in excess of 3,500 psi. It also possesses high compressive strength and is readily machinable.

Since EP13 is 100% reactive and does not contain any solvents or diluents, shrinkage upon cure is minimal. EP13 is an excellent electrical insulator.  It bonds well to a wide variety of substrates including metals, glass, ceramics, vulcanized rubbers and many plastics. This system has excellent resistance to chemicals including fuels, acids, bases, oils and many solvents. The standard color is gray and it has a service temperature range of -60°F to 450°F.

Cutting Edge Formulations

Our product line consists of advanced epoxies, silicones, polyurethanes, polysulfides, UV/LED cures and other specialty systems. Each compound is designed to meet specific application requirements. Our environmentally friendly systems are available in convenient packaging from small to large sizes.

Outstanding Technical Support

With years of experience in technical support, our team will be able to assess your application and recommend the most suitable polymer system to meet your specifications. We will continue to guide you throughout the design, prototype and manufacturing process. Master Bond offers replacements for discontinued products.

Latest Technological Advancements

As a worldwide manufacturer of polymer compounds, Master Bond is continuously working with universities and R&D labs to improve product performance. Our products are designed to maximize productivity, reduce waste, save energy and for dependable, long term durability.

About Master Bond

Master Bond is a leading adhesive manufacturer offering high quality adhesives, sealants, coatings, and potting compounds. Master Bond’s product line consists of epoxy adhesives, polyurethane, silicone, cyanoacrylate and latex adhesives.Master Bond’s structural adhesives offer design flexibility and provide excellent bonding performance with a vast array of 3,000 custom designed adhesive formulations.

Adhesive properties differ in viscosity, cure speed, chemical and temperature resistance, strength, electrical and thermal conductivity. Specific adhesive systems are designed to meet USP Class VI certification for medical use or NASA requirements for low outgassing.Master Bond products are successfully implemented in medical, optical, aerospace, electronic, and other hi-tech industries.

http://www.masterbond.com/

Source: Master Bond

For more information on this source please visit Master Bond.


Date Added: Jul 11, 2012 | Updated: Jul 16, 2012
