Dec 11 2012
Nordson DAGE, a division of Nordson Corporation, announces the new, upgraded technical specification for its class-leading X-ray inspection system that is dedicated to large-area PCBs.
XD7800 Ruby XL X-ray inspection systems
In keeping with the rest of Nordson DAGE’s jewel range of X-ray inspection systems, the system — now known as the XD7800 Ruby XL — is focused on and optimized for completely satisfying the needs of the electronics industry. Able to take a maximum board size of 1205 x 672 mm (47 x 26.4"), the XD7800 Ruby XL also includes the unique, maintenance-free, Nordson DAGE NT500 160kV sealed-transmissive X-ray tube that provides up to 10W of target power at sub-micron feature recognition and the exclusive Nordson DAGE 2 Mpixel χiDAT3 digital image intensifier detector with real-time image enhancements. Combined, the features of the XD7800 Ruby XL system allow it to cover all of the failure analysis and production inspection tasks that are required for large circuit board assemblies.
In addition to this new, improved specification, the XD7800 Ruby XL for the first time can utilize Nordson DAGE’s award winning X-Plane™ analysis system option that allows X-ray inspection in any plane within the assembly, or its components, without the need to destroy these large, usually very expensive assemblies, as would be necessary with traditional CT analysis.
Dr. David Bernard, Nordson DAGE Product Manager – X-ray systems, said, “This system configuration and specification is what the market has been asking for. Using a digital image intensifier detector with the sealed-transmissive X-ray tube in the Ruby XL means it has enough target power to image through the thickest backplane boards while still retaining sufficient resolution to detail the smallest features. Now when you add our X-Plane™ capability to this, which permits easy separation of features at different layers in the assembly to improve clarity of analysis and all without the need to cut the board, it definitely is the optimum solution.”
Source: http://www.nordson.com/
