ASTM A516 Grade 70 and ASME SA516 Grade 70 Carbon Steel Plate for Boilers and Pressure Vessels by Masteel

Topics Covered

Background
Carbon Steel Plate
Mill Test Certification of Carbon Steel Plate
ASTM A516 Grade 70 / ASME SA516 Grade 70 - Specifications and Standards
ASTM A516 Grade 70 / ASME SA516 Grade 70 - Chemical Composition
ASTM A516 Grade 70 / ASME SA516 Grade 70 - Mechanical Properties


Tag Links : ASTM A516 | ASTM A516 Grade 70 | ASTM A516 Gr 70 | A516 Grade 70 | A516 Gr 70


Background

Masteel UK Ltd are a global steel supply and stockholding company, supplying the engineering, power generation, petrochemical, oil & gas and nuclear industries.

Partnerships integrating the resources of the worlds most technically advanced steel mills enable Masteel to provide a single competitive source for the distribution of steel products worldwide,

Carbon Steel Plate

Masteel supply high quality carbon steel plate for boiler and pressure vessel fabrication which is ideally suited to the high standards set by the oil, gas and petrochemical industry - this is why we stock an extensive range of carbon plates according to ASTM A516 Grade 70 and ASME SA516 Grade 70.

Mill Test Certification of Carbon Steel Plate

The carbon steel plates come with mill certification in accordance with EN10204 3.1 or EN10204 3.2. Our plates are fully traceable, usually with hard stamping and we welcome any third party or customer inspection if required which can be arranged with the client.

ASTM A516 Grade 70 / ASME SA516 Grade 70 - Specifications and Standards

The specifications and standards of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are outlined in table 1.

Table 1. Equivalent Specifications and Standards of ASTM A516 Grade 70 / ASME SA516 Grade 70

Standard

Description

ASTM/ASME

A/SA516 - Grade 70

DIN Standard

-

British Standard

BS1501-224-490A/B

European Norm

EN10028 P355GH

ASTM A516 Grade 70 / ASME SA516 Grade 70 - Chemical Composition

The chemical composition of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are listed in table 2.

Table 2. Typical Chemical Composition of ASTM A516 Grade 70 / ASME SA516 Grade 70

Composition

Percentage %

Composition

Percentage %

C

0.10/ 0.22

Cu

0.3

Si

0.6

Ni

0.3

Mn

1/ 1.7

Mo

0.08

P

0.03

Nb

0.01

S

0.03

Ti

0.03

Al

0.02

V

0.02

Cr

0.3





ASTM A516 Grade 70 / ASME SA516 Grade 70 - Mechanical Properties

The mechanical properties of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are outlined in table 3.

Table 3. Typical Mechanical Values of ASTM A516 Grade 70 / ASME SA516 Grade 70

Properties

Value

Tensile Strength (N/mm2)

510/ 650

Yield stress/ min (N/mm2)

335

To find out more about Masteel's services and our range of carbon steel plate please visit Masteel.

Source: Masteel UK Ltd.

For more information on this source please visit Masteel UK Ltd.

Date Added: Jul 12, 2009 | Updated: May 13, 2014
Comments
  1. Cru Anne Cru Anne Philippines says:

    Is corrosion possible in 99.9% CO2 purity? Is corrosion also possible in 99.7% CO2 purity?

  2. Gazi Uddin Gazi Uddin Saudi Arabia says:

    PLEASE LET ME KNOW ACTUALLY WHAT IS THE BASIC DIFFERENCE BETWEEN A516 GR.70 AND A350LF2NCL2, THANKS

  3. EDUARDO CABRERA EDUARDO CABRERA Bolivia says:

    Por favor indicarme cual es la diferencia entre material SA516 Gr70N y SA516 Gr70, es decir el costo del acero normalizado es mayor en cuanto que el acero no normalizado, favor explicar.

    sds
    Eduardo

    • Nelson Alger Nelson Alger United States says:

      El "n" indica que esta normalizado o que puede aguantar mas presion porque esta relajado contra quebradizo.

  4. Randy Dolmage Randy Dolmage United States says:

    What is the bar stock that is equal to SME 516/70 plate?

  5. Naim Chebel Naim Chebel Lebanon says:

    What is the equivalent of SA 516 grad 70 or 60 in other standard?

    • Paul Murphy Paul Murphy United Kingdom says:

      Naim, Apologies for the delay in getting back to you.

      In the EN10028 standard P265GH is the equivalent for Gr 60 & P355GH is the equivalent for Gr 70.

      Hope this helps,
      Masteel

  6. Abhishek Agarwal Abhishek Agarwal India says:

    what is equivalent to ASTM 516 GRADE 70 IN INDIAN STANDARD

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Abhishek,

      There is no direct equivalent. The nearest would be IS 2002 Gr 3.

      Thanks,
      Paul Murphy (Masteel)

  7. Eduardo Montes Eduardo Montes Colombia says:

    Is SA 516-70 equivalent to Q345R?

  8. Javier Rsstto Javier Rsstto Argentina says:

    Is used A516 gr70 to low temperature (-30°C)? Do you know about other steel to manufacture energy towers of high voltage (1.32kv)? thanks

    • Paul Murphy Paul Murphy United Kingdom says:

      Buenos Dias Javier,

      I can tell you that our Gr 70 material is tested to -50 degrees C. I cannot advise on any alternative grades, you would have to consult a design engineer due to the electo-conductivity aspects.

      Hope this helps.

  9. mohamed ahmed mohamed ahmed Saudi Arabia says:

    Please we can use A 516 Gr.70 materials  four Sour Service

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Mohamed,

      My Quality Manager gave me the following feedback:

      "Use of A516 Grade 70 in a sour service environment totally depends of the severity of the sour service environment.

      Usually some form of additional HIC or SSC qualification of A516 Grade 70 material is required.

      Use this link: http://www.google.co.uk/url?sa=t&rct=j&q=&esrc=s&frm=1&source=web&cd=1&cad=rja&uact=8&ved=0CCEQFjAA&url=http%3A%2F%2Fwww.pipelineandgasjournal.com%2Fmaterial-selection-sour-service-environment&ei=5BG-VJzVHpX1asyNgIAO&usg=AFQjCNG7Nrp6y3nZQulkeRVFLsoYH-umbA&sig2=KsdtuMW2c81ezkjBJllUvQ

      as a good explanation of material selection in sour service environments."

      Hope this helps.

  10. Vijendra Kandari Vijendra Kandari U.A.E. says:

    Our Material Specification requires ASTM A285-GR. C However the vendor has supplied ASTM A516 Gr. 70. I think ASTM A516 Gr. 70 is a higher grade so can i get approval for the same. This grade indifference is for Blind Flange.

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Vijendra,

      A516 Grade 55 is the closest A516 equivalent grade to A285 Grade C.

      A516 Grade 70 is a "higher " grade than A285 Grade C.

      Approval of A516 Grade 70 instead of A285 Grade C is for the project would be at the discretion of the engineer.

      Hope this helps.

  11. Dilanka Mahesh Dilanka Mahesh Sri Lanka says:

    is SA 516 ok with syn-gas mixture applications ? process conditions are 30 bar, 60 C
    i have confused with possibility of the corrosion of this material, can u tell me something about it ?

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Dilanka,

      ASME SA516 is a standard specification for Carbon Steel pressure vessel plates for moderate and lower temperature service. Suitability for Specific Applications is totally dependent on the process environment and, as such, is the responsibility of the Design Engineer.

      We do not have specific data for ASME SA516 relating to corrosion.

      If you wish to receive further technical data for ASTM A516 (identical to ASME SA516) , and general information on Corrosion Problems during Oil & Gas Production please contact Masteel directly and I will be happy to send it across to you.

      Hope this helps.

  12. abdul raheem cholakkal abdul raheem cholakkal India says:

    Which one among ASTM A516 grade 70 and IS 2041 Grade R355 is better for manufacturing penstock pipe for Hydro electric project ? Can give a comparison ?

  13. waseem hassan waseem hassan Islamic Republic of Pakistan says:

    Is  A516, Grade 70 Equivalent to Corten Steel 490 or  Corten steel Grade A ?
    We intend to use A516, Grade 70 instead of Corten Steel Grade A & Corten Steel 490 for fabrication work of Regenerative Air Preheater. Temperature range is 320 C.

    Please advise us.

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Waseem,

      ASTM A516 Grade 70 is a Carbon Steel intended for service in Welded pressure vessels for Moderate and Lower Temperature Service.
      While Corten 490 & Corten A are primarily Atmospheric Corrosion Resistant Steels.

      As such Masteel cannot advise use of either grade of steel. This should be determined by the Design Engineer for the particular project.

      If you require any further information I have a couple of supporting documents that I would be happy to send to you via email - please contact Masteel directly for this.

      Hope this helps.

  14. Harsha vashista Harsha vashista India says:

    CAN WE USE S355J2+N, en 10025-2 in place of SA516 Gr 70?

    • Paul Murphy Paul Murphy United Kingdom says:

      Hi Harsha,

      EN10025-2 S355J2+N is a Structural Steel.
      ASME SA516 Grade 70 is a Pressure Vessel Steel.

      So S355J2+N is NOT usually used as a replacement for SA516 Gr 70.
      But this decision is the responsibility of the Design Engineer for the particular project.

      A more acceptable replacement grade could be EN10028-3 P355NL1, but again, this decision is the responsibility of the Design Engineer for the particular project.

      Hope this helps.

  15. sunil kaushik sunil kaushik United States says:

    what is equivalent to ASTM 516 GRADE 70 IN INDIAN STANDARD

    • Paul Murphy Paul Murphy United Kingdom says:

      Dear Sunil,

      The nearest would be IS 2002 Gr 3.

      Regards,
      Paul Murphy
      Masteel UK Ltd

  16. Kiran Kumar Singh Kiran Kumar Singh India says:

    SA-516 Gr 70N is available in rod
