Systech Illinois

Systech Illinois
Thame Park Business Centre, Wenman Rd
Thame OX9 3XA
United Kingdom
PH: +44 (1844) 216838
Visit Systech Illinois Website or Request Quote for Further Information

Primary Activity

Manufacturer of Moisture, gas, and oxygen analyzers

Company Background

Systech Illinois is a manufacturer of moisture, oxygen and gas analyzers for industries worldwide. Our manufacturing plants in the UK and U.S (Systech Instruments, UK and Illinois Instruments, U.S)produce oxygen analyzers for the process industry, headspace gas analyzers for the food & pharmaceutical industry and oxygen and water vapor permeation analyzers for the packaging industry. With sales and support facilities worldwide and 30 years as one of the leading gas analysis experts, Systech Illinois can offer technical solutions to many applications.

Gas Analysis for the Food and Packaging Industry

Our oxygen and carbon dioxide headspace analyzers offer fast, easy to use, accurate gas analysis of gas flushed food packages and headspace analysis of any kind. Systech Illinois’ gas analyzers can be used effectively with packages of all sizes and there are portable and waterproof versions available. Our range of oxygen permeation analyzers and water vapor permeation analyzers offer precise, accurate measurements for all packaging film, finished package and PET bottles.

Oxygen Analyzers for Process Industry

Our range of process oxygen analyzers provides measurements from trace ppb levels up to high percentage levels. Available in wall mounted IP66-rated, benchtop and rack mounted versions, our oxygen analyzer instruments include intrinsically safe units. The EC900 oxygen analyzer use electrochemical cell, the ZR800 oxygen analyzer use zirconia oxide ceramic, and the PM700 oxygen analyzer use paramagnetic technology.

Moisture Analysis for Process Industry

For analysis of moisture the MM500 moisture analyzer uses phosphorous pentoxide and the MM400 moisture analyzer uses aluminium oxide, to measure from as low as 0.01 to 1000 ppm, or in dewpoint °C or °F. Systech Illinois’ moisture analyzers are panel, bench or wall mounted in a weatherproof cabinet, or rack mounted.

Thermal Conductivity Analyzers for Process Industry

Systech Illinois’ 542 is a versatile, programmable gas analyzer based on the principle of thermal conductivity, capable of measuring almost any combination of gases.

ATEX Approved Analyzers

For hazardous areas, the EC91 and EC92DIS ATEX approved analyzers are for use in EEx ia IIC T4 Zone 0 areas. These instruments are capable of measuring both ppm and percentage levels of oxygen.

Systech Illinois products allow customers to:
•    Measure the level of oxygen
•    Analyze moisture content of almost any gas
•    Test packaging for the permeation of oxygen or water vapor
•    Measure the headspace gas of Modified Atmosphere Packaging
•    Measure oxygen in a hazardous area
•    Obtain expert advice on measuring almost any gas in a binary mixture.
