P235GH Pressure Vessel Steel

P235GH is a European specified steel for use in pressure vessels, boilers and heat exchangers.

The composition of this steel makes it ideal for applications where elevated working temperatures are the norm and the material is used by fabricators throughout the oil, gas and petrochemical industry.

P235GH is a normalized carbon alloy steel and is available ex-stock from our warehouse with mill certification and stamping. This EN10028 steel grade supersedes the older BS and DIN standards (Grades BS 1501-161-360A and DIN H 1, respectively).

The technical details are given in the tables below.

P235GH - Chemical Composition

The Chemical Composition of EN 10028 P235GH is given in the table below.

Table 1: Chemical Composition of EN 10028 P235GH

Element

% by mass

Element

% by mass

Carbon (C)

≤0.16

Silicon (Si)

≤0.35

Manganese (Mn)

0.60 to 1.20

Phosphorous (P) (max)

0.025

Sulphur (S) (max)

0.015

Aluminium (Al)

≤0.020

Nitrogen (N)

≤0.012

Chromium (Cr)

≤0.30

Copper (Cu)

≤0.30

Molybdenum (Mo)

≤0.08

Niobium (Nb)

≤0.020

Nickel (Ni)

≤0.30

Titanium (Ti) (max)

0.03

Vanadium (V)

≤0.02

The combined quantities of Chromium, Copper and Molybdenum should not exceed 0.70%



P235GH - Mechanical Properties

The mechanical properties of EN 10028 P235GH are outlined in the table below.

Table 2: Mechanical Properties of EN 10028 P235GH

Grade

Type

Thickness
(mm)

Yield Strength
MPa (min)

Tensile Strength
MPa

Elongation
% (min)

Impact Energy
(KV J) (min)

-20°

+20°

P235GH

Normalized

≤16

235

360 to 480

24

27

34

40





16> to ≤40

225

360 to 480

24

27

34

40





40> to ≤60

215

360 to 480

24

27

34

40





60> to ≤100

200

360 to 480

24

27

34

40





100> to ≤150

185

350 to 480

24

27

34

40





150> to ≤250

170

350 to 480

24

27

34

40

(Please note: the technical information above is for guidance only - for exact specifications please check with Masteel)

This information has been sourced, reviewed and adapted from materials provided by Masteel UK Ltd.

For more information on this source, please visit Masteel UK Ltd
