Topics Covered
Background
Chromium Molybdenum Steel - A387 Grade 11 Class 2
Different Grades of ASTM / ASME A387 Grade 11 Chromium Molybdenum Steel
Equivalent Grades of A387 Grade 11 Chromium Molybdenum Steel
Chromium and Molybdenum Composition of A387 Grade 11 Chromium Molybdenum Steel
Tensile Requirements for A387 Grade 11 Chromium Molybdenum Class 2 Plates
Chemical Composition of A387 Grade 11 Chromium Molybdenum Steel
Tensile Test Requirements for Chromium Molybdenum Steel
Recommended Testing Procedures for Chromium Molybdenum Steel
Background
Masteel UK Ltd are a global steel supply and stockholding company, supplying the engineering, power generation, petrochemical, oil & gas and nuclear industries.
Partnerships integrating the resources of the worlds most technically advanced steel mills enable Masteel to provide a single competitive source for the distribution of steel products worldwide,
Chromium Molybdenum Steel - A387 Grade 11 Class 2
As a quality chrome molybdenum steel, A387 Grade 11 Class 2 is used in a variety of industries and is highly effective, particularly in the oil, gas and chemical industry, where liquids and gases are often stored at high temperature (see pressure vessels). The higher levels of chromium also provide excellent corrosion and oxidation resistance.
.jpg)
Different Grades of ASTM / ASME A387 Grade 11 Chromium Molybdenum Steel
Masteel's range of ASTM / ASME A387 Grade 11 chrome molybdenum steel products are available in different grades listed in the following.
- ASTM A387 Grade 11 Class 2
- ASME SA387 Grade 11 Class 2
Equivalent Grades of A387 Grade 11 Chromium Molybdenum Steel
The equivalent grades of A387 Grade 11 chrome molybdenum steel are as follows:
|
BS |
EN |
ASTEM/ASME |
DIN |
|
621B |
- |
A387-11-2 |
- |
Chromium and Molybdenum Composition of A387 Grade 11 Chromium Molybdenum Steel
The chromium and molybdenum contents of A387 Grade 11 chrome molybdenum steel (according to the ASTM specification) are outlined in the following table.
|
Designation |
Nominal Chromium Content (%) |
Nominal Molybdenum Content (%) |
|
A387 Grade 11 |
1.25% |
0.50% |
Tensile Requirements for A387 Grade 11 Chromium Molybdenum Class 2 Plates
The tensile requirements for A387 Grade 11 Chrome Molybdenum Class 2 plates are listed in the following table.
|
Designation |
Requirement |
Grade 11 |
|
A387 Grade 11 |
Tensile strength, ksi [MPA] |
75 to 100 [515 to 690] |
| |
Yield strength, min, ksi [MPa]/(0.2% offset) |
43 [310] |
| |
Elongation in 8 in. [200mm], min % |
18 |
| |
Elongation in 2 in. [50mm], min, % |
22 |
| |
Reduction of area, min % |
- |
Chemical Composition of A387 Grade 11 Chromium Molybdenum Steel
The chemical composition of A387 Grade 11 chrome molybdenum steel from heat and product analysis is summarised in the following table.
|
Element |
Analysis |
Chemical Composition (%) inc. Grade & UNS No. |
| |
|
Grade 11 (UNS: K11789) |
|
Carbon: |
Heat Analysis:
Product Analysis: |
0.05 - 0.17
0.04 - 0.17
|
|
Manganese: |
Heat Analysis:
Product Analysis: |
0.40 - 0.65
0.35 - 0.73
|
|
Phosphorus: |
Heat Analysis:
Product Analysis: |
0.035
0.035 |
|
Sulphur (max): |
Heat Analysis:
Product Analysis: |
0.035
0.035 |
|
Silicon: |
Heat Analysis:
Product Analysis: |
0.50 - 0.80
0.44 - 0.86
|
|
Chromium: |
Heat Analysis:
Product Analysis: |
1.00 - 1.50
0.94 - 1.56
|
|
Molybdenum: |
Heat Analysis:
Product Analysis: |
0.45 - 0.65
0.45 - 0.70
|
Tensile Test Requirements for Chromium Molybdenum Steel
The material shall be tested using a test specimen will confirm to the tensile requirements as outlined in tensile requirements for A387 Grade 11 Chrome Molybdenum Class 2 plates above.
Recommended Testing Procedures for Chromium Molybdenum Steel
The following requirements and testing procedures (which are not mandatory) are considered suitable for Chromium Molybdenum steel:
- Vacuum treatment
- Product Analysis
- Additional Tension Test
- Charpy V-Notch Impact Test
- Drop Weight Test
- High Temperature Tension Test
- Ultrasonic Examination
- Magnetic Particle Examination
To find out more about Masteel's services and ASTM A387 Grade 11 Class 2 Chromium Molybdenum steel plates which we can supply directly to you please visit Masteel.
