Thermal analysis is the study of materials as a function of changing temperature. There are several thermal analysis techniques such as: Thermogravimetric analysis (TGA) which measures weight changes; Thermal Conductivity, a materials ability to transmit heat; Differential Thermal Analysis (DTA) which measures exothermic and endothermic reactions; Differential Scanning Colorimetry (DSC) which measures the heat required to raiuse the sample temperature; Dilatometry and Thermomechanical Analysis (TMA) which measure dimensional changes with changing temperature and; Dynamic Mechanical Analysis (DMA), dynamic mechanical thermal analysis (DMTA) which looks at viscoelastic properties of polymers.
If you'd like us to help you source a Quotation for Thermal Analysis Equipment please click here. Once submitted, we will try and place you in contact with a suitable Thermal Analysis Equipment supplier within 48 hours.
Featured Equipment
The model AHT-12 thermal flux meter available from ITI is a sophisticated solid state, flat-plate transducer, which is designed for direct measurement of heat flow.
The Model HT-50 Thermal Flux Meter available from ITI is a solid state, flat-plate transducer, which is particularly designed for direct measurement of heat flow.
The models A~E thermal flux meters available from ITI are advanced solid state, flat-plate transducers that are specifically designed to directly determine the heat flow.
Other Equipment
The BINDER FED Series heating chambers offer a very large capacity, and are adaptable to many different applications.
The VeraSpec thermal desorption spectrometer (TDS) from Extrel is a scientific tool used for investigating chemical species desorbed from a heated sample.
The METTLER TOLEDO DMA/SDTA861e is the latest DMA introduced in the market. In comparison with conventional DMA instruments it offers new and unique performance benefits: A frequency range up to 1000 Hz for material behavior simulation and accurate determination of moduli through the presence of a dedicated force sensor.
The new DSC 404 F1 Pegasus®, High-Temperature Differential Scanning Calorimeter, is designed for the exact determination of specific heat of high-performance materials at high temperatures. The new concept of the DSC 404 F1 Pegasus® allows configuration for up to five different furnace types, easily interchangeable by the user, for a wide temperature range within -150°C...2400°C.
The T600-series infrared cameras from FLIR are suitable for applications requiring high-resolution thermal and daylight imagery.
The new Flash DSC 1 represents a quantum leap in Thermal Analysis and opens up new frontiers in the field of materials characterization.
FLIR’s T-Series infrared cameras are portable and easy to use, and offer users outstanding cost-effective infrared image quality.
VITA technology adds high resolution nanoscale thermal characterization capabilities to Bruker's Dimension® Icon® AFM, Dimension Edge AFM, and MultiMode® 8 SPM.
The DSC 204 HP Phoenix® is a high-pressure differential scanning calorimeter. The thermal effects in a sample can be tested based on the type of gas. The atmosphere in the sample chamber can be dynamic or static.
NETZSCH’s STA 449 F5 Jupiter is a top-loading system designed for thermogravimetry and differential thermal analysis.
The Binder oven and chamber range covers all types of routine applications and also highly technical and specific tasks, taking pride in offering unique precision in both areas.
The TG 209 F1 Libra thermobalance allows you to measure mass change of materials as a function of temperature in the range 10-1100°C. The instrument has been designed for ease of use and to protect delicate components to ensure minimum down time.
Thermal conductivity and thermal diffusivity are the most important thermophysical material parameters for characterizing the thermal transport properties of a material or component. The Laser Flash technique is currently the most widely accepted method for precise measurement of the thermal diffusivity and the LFA 427 is the number one instrument on the world market. High precision and reproducibility, short measurement times, variable sample holders and defined atmospheres are outstanding features of LFA measurements over the entire application range from -70°C to 2800°C.
HFM 436 Lambda, the heat flow meter from NETZSCH, is designed for precise thermal conductivity testing of insulation materials.
The NETZSCH Photo-DSC 204 F1 Phoenix®, Differential Scanning Calorimeter, works in the temperature range from -100°C to 200°C. The instrument has a gas-tight measuring cell and the purge gas control is regulated by a mass flow controller (MFC). For our Photo-DSC 204 F1 Phoenix®, most standard industry or laboratory lamps for cationic or radically curing material systems can be used.
The new dilatometer DIL 402 Expedis Classic represents a robust and easy-to-use all-in-one instrument. All instruments of the DIL Expedis series feature the revolutionary NanoEye measuring cell; a new dimension in measuring range and accuracy.
The primary scope of TG-GC-MS coupling is to detect, separate and analyze organic components. It is also possible to use the coupled GC-MS for detailed gas analysis to further improve the temperature-programmed pyrolysis of organic materials, biomass, renewable solid fuels, carbonaceous materials, and polymers in the TG/STA. The volatile products emitted during combustion processes can be determined with high sensitivity and resolution at various oxygen content levels.
The heart of the TMA 402 Hyperion® is a highly precise inductive displacement transducer (LVDT). This technology has stood the test of time; it is also used for dilatometers and allows measurement of even the smallest of length changes, into the nanometer range (digital resolution of 0.125 nm).
Markes, a company specializing in high-quality analytical thermal desorption products, offers quality-assured thermal desorption tubes, spares and accessories.
The FLIR X8000 sc/X6000 sc series thermal imaging cameras provide advanced connectivity and excellent thermal measurement performance. The FLIR X8400 sc produces thermal images of about 1280 x 1024 pixels for ensuring high measurement accuracy and providing smallest image details.
The multi-functional design of the DEA 288 Epsilon (including furnace or laboratory press) allows for the application of a great variety of different test conditions such as heat, cold, humidity or UV light.
NETZSCH’s SBA 458 Nemesis has a unique measurement setup, which accommodates more sample geometries than usual for this method.
The versatile Premium DSC 204 F1 Phoenix® fascinates with its unique concept: all essential operational components are integrated into the instrument and optional add-ons can be installed anytime on site.
Life Science professionals know that the thermodynamic driving forces of macro-molecular interactions are critical parameters for the design of effective biomedical and pharmaceutical treatments. Calorimetry has become the method of choice for characterizing the thermodynamic driving forces of critical molecular interactions and defining molecular stabilities.
NETZSCH’s STA 2500 Regulus features a highly reliable, fully equipped instrument package for STA measurements up to 1600°C.
The FLIR SC5000 series has high spatial resolution, accuracy and sensitivity. 320 x 256 or 640 x 512 pixels format Indium Antimonide (InSb) focal plane array is provided in the FLIR SC5000 series that has a frame rate of about 380 or 100 Hz.
The TG 209 F3 Tarsus® is designed to perform thermogravimetric measurements. It operates in temperatures ranging from room temperature to 1000°C. Heating rates ranging from 0.001K/min up to 100K/min can be selected easily.
The Q400 thermomechanical analyzer available from TA Instruments is a research-grade thermomechanical analyzer (TMA) that provides excellent flexibility in test probes, operating modes, and available signals.
The new DMA 242 E Artemis combines ease of handling with the user-friendly Proteus® measurement and evaluation software. This makes it fast and easy to characterize the dynamic-mechanical properties as a function of frequency, temperature and time.
Leco offers the advanced AF700 Ash Fusion Determinator that uses Windows-based software to automatically check the temperatures of ash cone deformation in mold powders, coke ash, and coal ash.
Markes’ UNITY is an advanced analytical thermal desorption instrument designed for real-time analysis of SVOCs, VOCs and thermally labile compounds accumulated onto sorbent tubes.
Guarded Hot Plates are employed in the most demanding R&D and QA applications where faster instruments (such as guarded heat flow meters) do not suffice, or do not possess the broad operating range desired.
Portable cameras are highly sensitive, and have advanced features. They have the capacity to generate a combination of infrared and visible spectrum images having high temperature measurement accuracy and quality.
APTAC 264 takes the testing of chemical reactivity a step forward by enabling the user to acquire much faster temperature and pressure rise data than did the earlier designs. The APTAC 264 can function as: High-performance closed-cell adiabatic calorimeter; High-temperature and high-pressure reaction calorimeter; Open test cell from which effluent can be discharged and analyzed for emergency relief system studies using the DIERS methodology of the American Institute of Chemical Engineers
The Binder incubator BF115 with mechanical convection is suited for all gentle incubation applications, especially under full load and large batch throughputs. This incubator is has extremely low temperature variation and has rapid recovery times.
The FLIR A305 sc - A325 sc and FLIR A645 sc - A655 sc infrared cameras are designed to keep the thermal efficiency of the development project under constant control. It prevents design faults in the making, ensures quality and cuts time-to-market.
A number of leading companies consider the RFM300+ series refractometers as the ultimate instrument to be installed in challenging factory environments and also as a primary quality control tool.
The 3D-DMA employs experimental techniques grounded in metals testing experience. Extensometers measure strain locally on axially loaded specimens, rather than relying on contact point displacement on flexing beams. The system concurrently measures dynamic Young's Modulus, E*, and viscoelastic Poisson's ratio, �*.
The isothermal battery calorimeter (IBC) 284 is designed for examining the performance and safety of energy storage devices, such as large lithium ion batteries used widely in airplanes, electric vehicles, stationary power back-up, and storage applications.
The LT-451 Dielectric Cure Monitor is a versatile compact instrument developed for research and development, quality assurance or quality control and production applications that involve thermoset materials such as resins, composites, paints and coatings.
The i-Thermotek 2710 thermal shrinkage tester from Labthink is specifically designed for quantitative analysis of shrinkage ratio, contracting force and shrinking force of heatshrinkable films.
The LFA 467 HT HyperFlash® is a type of light flash apparatus manufactured by Netzsch for precise thermal conductivity and thermal diffusivity measurements between RT and above 1250°C. The LFA 467 HT HyperFlash® is based on the well-established LFA 467 HyperFlash® technology.
Malvern’s MicroCal Auto-iTC200 is a fully automated, high sensitive isothermal titration calorimeter that provides direct measurement of all binding parameters in a single experiment.
Portable cameras are capable of producing a combination of infrared and visible spectrum images with high temperature measurement accuracy and quality. They are highly sensitive, and have advanced features. They include laser pointer, contrast optimizer, and other advanced features.
Markes offers TD-100, an automated, high-throughput thermal desorption system designed for fast and automated processing of up to 100 sorbent sample tubes in one sequence.
The TMA 801 operates in a vertical orientation, making it ideal for the analysis of sintering, RCS (rate controlled sintering), viscoelastic behavior and the determination of softening temperatures. The linear motor generates a constant throughout the experiment, ensuring that contact is maintained with the sample regardless of dimension change.
NETZSCH’s Accelerating Rate Calorimeter 254 (ARC® 254) offers adiabatic calorimetry information in a safe, controlled laboratory setting.
The novel CB series offers optimal growth conditions for cell cultures. The anti plenum concept, the 180°C sterilization routine with the world's first sterilizable CO2 sensor and other unique BINDER technologies satisfy the highest requirements for best possible cell growth and maximum sample safety in the premium class of BINDER CO2 incubators.
The new STA 449 F1 Jupiter® combines unlimited configuration flexibility and unmatched performance in just one instrument.
The new Concavus pan available from NETZSCH has a slight concave bottom geometry that produces an accurately defined contact surface between the pan bottom, sample and sensor, and thus helps in improving the reproducibility of the measurement results.
The FLIR ResearchIR software is an easy-to-use thermal analysis software suitable for science and research applications. It performs a number of tasks like reporting, camera system command and control, high speed data recording, data sharing, real-time or playback analysis.
The vertical optical dilatometer Misura® ODHT from Expert System Solutions is a non-contact device specifically designed to handle thermo mechanical measurements following the process of sintering, expansion, or bloating of materials and analyzing the sample across the whole industrial firing cycle.
The Instron® CEAST HV500 is the latest instrument design to perform HDT and VICAT tests at high temperatures, up to 500°C, making this instrument ideal for research and quality control applications as it is ensuring the capability to test the new generations of techno-polymers, characterized by their excellent properties at high temperature.
The FL-5000 is perhaps the most flexible system of its kind. It allows the selection of subsystems and options to assemble a configuration that best suits any application. Many of these elements are interchangeable or selectable as an addition at a later date to grow with changing needs.
The PERSEUS® TG 209 F1 is a robust, compact and cost-effective instrument capable of delivering excellent performance. It is a combination instrument that possesses the advantages of the FT-IR instrument and the TGA, thus making it ideal for use in any laboratory.
Quick Mix Epoxy System from Buehler is a provided with quick mix epoxy cartridges containing pre-measured resin and hardener.
Malvern Instruments has introduced MicroCal iTC200, a low volume isothermal titration calorimeter for analysis of biomolecular interactions.
The accelerating rate calorimeter 244 (ARC® 244) is designed for safe and accurate measurement of the quantity and rate of heat release relating to the processing or storage of chemicals. The instrument was earlier named as TIAX ARC 3000.
The new GHP 456 Titan® is the ideal tool for researchers and scientists in the field of insulation testing. Based on the well-known, standardized guarded hot plate technique (e.g. ISO 8302, ASTM C 177 or DIN EN 12667), the system features unrivalled performance over an unmatched temperature range.
The expertise of Harper International in advanced thermal processing design helps them offer the latest fully integrated production lines for carbon nanotubes, carbon fiber and metal oxide materials.
Malvern Instruments has introduced a fully automated, high-throughput, high-sensitivity differential scanning calorimeter called MicroCal VP-Capillary DSC.
NETZSCH offers a new exchangeable calorimeter module for the MMC 274 Nexus particularly dedicated to coin cell battery studies.
DMA25 is a desktop DMA offering a high force range up to 25N and outstanding flexibility from glass transition determination to immersed tests, which makes it a powerful thermomechanical testing platform.
The LTF-631 High Speed Dielectric Cure Monitor is designed for the study of rapidly reacting materials in Research and Development, Quality Assurance or Quality Control, and Production applications involving thermoset materials such as resins, composites, paints and coatings.
Malvern’s MicroCal VP-DSC is a highly sensitive differential scanning calorimeter designed for studying samples in solution.
The new dilatometer DIL 402 Expedis Select and Supreme offer state-of-the-art dilatometer technology and are desiged for a wide range of sophisticated applications. All instruments of the DIL Expedis series feature the revolutionary NanoEye measuring cell; a new dimension in measuring range and accuracy.
The heart of a TGA is the balance cell. Our TGA instruments use the world’s best micro and ultra-micro balances. By using one of the three removable sensor types the TGA/DSC 1 simultaneously measures heat flow in addition to weight change. Thanks to its modular design, the TGA/DSC 1 is the ideal instrument for manual or automated operation in production and quality assurance through to research and development.
Fourier transform infrared spectrometer (FT-IR) spectroscopy is a well-established analytical method. FT-IR spectrometers are used in numerous laboratories.
Thermal conductivity and thermal diffusivity are the most important thermophysical parameters for characterization of the thermal transport properties of a material or component. The TCT 426 thermal conductivity tester enables the use of all three of the methods described in easily interchangeable, pre-wired measuring frames.
Preiser Scientific's new 6000 Series of Plastometer/Dilatometer controllers provide for great flexibility by allowing two tests to be run with only one controller.
The FLIR A305 sc-A325 sc and FLIR A645 sc-A655sc infrared cameras are used for maintaining the thermal efficiency of development project under constant control. These cameras reduce time-to-market and avoid occurrence of faults while designing.
FLIR has developed the advanced T1030sc infrared camera for applications requiring rapid raw data streaming and high thermal sensitivity. The uncooled LWIR camera includes a highly sensitive HD detector and comes with customizable features.
The horizontal optical dilatometer Misura® ODLT designed by TA Instruments was launched in the market after patenting in 2001.
FLIR cameras are designed with short exposure times that facilitate freezing of motion and accurate temperature measurements. They are suitable for fast-moving targets and high-speed thermal events.
The Ceramicomb-1” is designed for use in presses, molds or harsh environments where a rugged, reusable dielectric sensor is desired.
Malvern’s MicroCal VP-ITC is a highly sensitive, easy-to-use isothermal titration calorimeter that provides the ability to study any biomolecular interactions.
The LFA 467 HyperFlash® from NETZSCH is a light flash apparatus offering unique dimensions in the measurement of thermal diffusivity and conductivity.
Orton dilatometers are designed to measure the dimensional changes of ceramics, glasses, metals, carbon composites, cermets, minerals, and polymers as a function of temperature.
CMP 22 includes all the features of CMP 21 but uses very high quality domes for improved directional response, a wider spectral range and reduced thermal offsets.
The Model 603 HDTM and the Model 303 HDTM are the latest generation of Tinius Olsen’s digitally controlled Automatic Deflection Temperature/Vicat test equipment. The 603 HDTM is capable of testing up to six different specimens simultaneously, and the smaller 303 HDTM can test up to three specimens simultaneously, both with an automated testing sequence that proceeds according to user defined control and configuration parameters.
The Discovery TGA features our industry-leading thermobalance, innovative IR-heated furnace, patented Hi-Res TGA, and an autosampler unmatched in flexibility and reliability.
The IR camera bench top test kits manufactured by FLIR are a set of precision cameras that can replace thermocouples and spot pyrometers.
TA Instruments’ DIL805A/D is a unique dilatometer designed for determining the deformation parameter and for creating continuous cooling, TTT-, and DTTT- diagrams.
Suitable for the widest range of routine thermal expansion measurements, the DIL 801 and DIL801L are horizontally configured single-sample dilatometers. The DIL 801 is designed for measurements under vacuum or inert gas while the DIL 801L is designed for measurements in air, making the DIL 801L ideally suited to measuring ceramic materials which are often processed in air.
Thermal imaging cameras are used for research and development applications. The SC35/SC15 and SC5 packs FLIR systems are capable of performing thermal imaging.
The MMC 274 Nexus available from NETZSCH is a multiple module calorimeter and includes two parts: the base unit with built-in electronics and the exchangeable calorimeter module.
The PERSEUS® STA 449 F1/F3 is basically a combination of two well-established instruments - the NETZSCH STA 449 F1/F3 Jupiter® and Bruker Optics’ FT-IR spectrometer.
NETZSCH’s STA 449 F3 Jupiter® is a simultaneous thermal analyzer that combines the benefits of a true differential scanning calorimeter and a high sensitive thermobalance.
Harper pioneered the Microline concept based on the flexibility to change and modify for the needs of customers in research and development of advanced fiber processing techniques.
CMP 11 makes use of the temperature compensated detector technology originally developed for the CMP 22 and is a step up in performance from the CMP 6. It is especially ideal for meteorological networks and the reduced response time of 1.66s (63%) meets the requirements for solar energy applications.
TA Instruments’ DIL 806 optical dilatometer is an advanced and versatile tool designed for thermal expansion and contraction measurements. It is perfectly suited for measuring thin, irregularly-shaped soft sample lengths without contact.
Unitherm 1000 is a fully computerized dilatometer system designed to measure dimensional changes of a specimen brought about by changes in its thermal environment. Linear thermal expansion coefficient, annealing characteristics and other physical or chemical changes manifesting themselves in a change of linear dimension can be precisely determined.
Lambient Technologies offers the LTT-203 Process Controller, which provides an ideal solution for controlling the temperature of heating devices such as kilns, hot plates, ovens etc. The LTT-203 is compact and portable and accepts Type B, E, J, K, L, R, S, and T thermocouples. It does not require any assembly or set-up.
CMP10 is the secondary standard pyranometer with very good price-quality-performance ratio on the market. Based on the established CMP 11 technology, CMP10 extends this quality to applications where maintenance is difficult and/or forms a major part of the cost of ownership.
The Discovery DSC provides unmatched precision, accuracy, industry-leading sensitivity and resolution.
The TGA/STA-QMS 403 D Aëolos® quadrupole mass spectrometer is a new compact mass spectrometer with a heated capillary inlet system for routine analysis of gases and, in particular, volatile decomposition products of thermal analysis.
The innovative DSC 214 Polyma is robust, easy to use and precise. The novel design of the instrument that includes everything required for successful DSC investigations, regardless of whether the user is a beginner or an experienced professional.
