Wafer Mapping Systems

Wafer Mapping System rapidly and automatically creates a map of the magnetic properties of wafers. The Wafer Mapping System is available both as a low-cost manual-loading tool for use in development or limited-production environments and also as a fully-automated tool for use in volume production.
Request a Quote for Wafer Mapping Systems
If you'd like us to help you source a Quotation for Wafer Mapping Systems please click here. Once submitted, we will try and place you in contact with a suitable Wafer Mapping Systems supplier within 48 hours.
Equipment
MDP Ingot - Ingot or Wafer Mapping System from Freiberg Instruments
Electrical characterisation tool for mapping of bricks (or wafers) with mea- surement times of less than four minutes for a 500 mm brick at 1 mm resolution. Completely touch free measurements.
F80-t Film Thickness Mapping System for Patterned Wafers from Filmetrics
Process engineers want film thickness measurements fast and without a lot of hassle. Our innovative Thickness Imaging™ technology allows Filmetrics to offer easy recipe set up and industry-leading throughput, at a mere fraction of the cost of competing metrology tools.
QuadPro Resistivity Wafer Mapping System from Lucas Signatone
The Signatone QuadPro Process Development Resistivity System is available in both manual and automatic 8" and 12" systems. The manual system includes a ball bearing stage and can be upgraded at a later time to add auto-stepping capability. The automatic systems are motorized and can automatically step through 9, 25, 49, or 121 test points on wafers of size 100 mm, 125 mm, 150 mm, 200 mm, or 300mm.
LM Wafer Mapping Sensors from MultiMetrixs
Improve the reliability and throughput of your robotic wafer handling systems with the next generation wafer mapping sensors from MultiMetrixs. The most technically advanced and cost effective range of wafer mapping sensors on the market today.
MaxMile EpiEL Wafer Electroluminescence Mapping System
MaxMile EpiEL system is a virtual LED device fabrication & characterization system which can be used to measure LED device parameters directly on epiwafers. Without any costly and time-consuming device fabrication, yet as through a finished device, EpiEL reveals not only the electro-luminescence (EL) but also the electrical properties of the material.
WT-2000PVN Multifunction Wafer Mapping Tool from Semilab
The WT-2000PVN is a tabletop measurement system, capable of performing a variety of measurements on PV cells, wafers, and blocks. The base system includes the overhead functions, and you configure the measurement capabilities to match your specific needs.
