Sialon - Physical and Mechanical Properties and Applications of Syalon 110

Image Credits: shutterstock.com/g/buhanovskiy

Syalon 110 is a composite grade of the Si-Al-O-N (sialon) family of ceramics, which is processed under carefully controlled conditions to give a material with some unique properties.

Syalon 110 was originally developed as a break ring for the horizontal continuous casting of steel. As such, its properties include improved corrosion resistance to steel compared to other Syalons, outstanding thermal shock resistance and usable up to temperatures in excess of 1450°C.

Physical and Mechanical Properties of Syalon 110

The table below lists typical mechanical, thermal and electrical property data for Syalon 110.

Properties

Value

Units

3 point RT Modulus of Rupture (Specimen 3 x 3 x 50, span 19.05mm)

500

MPa

Weibull Modulus

10

-

RT Unit Tensile Strength

250

MPa

RT Hardness (HRA)

88

-

RT Hardness (Vickers Hv0.3)

1200

Kg/mm2

Fracture Toughness K1C

3.5

MPam1/2

Density

2.65

g/cc

Porosity

< 10

%

Thermal Expansion Coefficient (0-1200°C)

3.04×10-6

K-1

RT Thermal Conductivity

21.3

W/m/K

Thermal Shock Resistance

800

ΔT°C quenched in water

Electrical Resistivity

10

Ohm m

Typical physical property data obtained under test conditions. All properties have been measured by independent testing authorities. The values given only apply to the test bodies on which they were determined, and therefore can only be recommended values.

Applications of Syalon 110

Syalon 110 is typically used in specialist applications where extreme high temperature durability, thermal shock resistance and corrosion resistance are required. These include thermocouple protection sheaths in ferrous and non-ferrous molten metal applications and as a break ring for horizontal continuous casting of steel.

Exploiting Advantages of Syalon 110 for Your Applications

The successful integration of ceramics into industrial and engineering systems requires close collaboration between you, the end-user, and ourselves, the material suppliers. Our Technical Specialists are available to discuss your requirements in detail and assist in exploiting the significant advantages which Syalon 110 has to offer.

This information has been sourced, reviewed and adapted from materials provided by International Syalons.

For more information on this source, please visit International Syalons.
