Electric vehicle (EV) batteries produce significant heat during operation, especially under fast-charging or high-power conditions. Effective thermal management is therefore critical for ensuring safety, extending lifetime, and enhancing battery performance.
Image Credit: bclass/Shutterstock.com
This article examines the materials and design approaches for controlling EV battery heat, with a focus on custom thermal interface pads and heat spreaders.
By improving heat conduction between cells and cooling systems, these components help maintain uniform temperatures and reduce the likelihood of thermal runaway.
Understanding these materials, including gap filler pads, phase change materials, and flexible graphite sheets, enables engineers to optimize thermal control within space and performance constraints.
Rapid custom manufacturing further supports fast prototyping and integration during accelerated EV development cycles.
Thermal Management Challenges in EV Batteries
High Heat Flux and Hotspots
Lithium-ion cells produce many watts of heat during charge and discharge cycles. This heat can lead to hotspots and uneven temperature distribution in tightly-packed modules, further resulting in cell imbalance, accelerated degradation, or, in severe cases, thermal runaway.
Efficient heat extraction and distribution are essential for maintaining safe cell temperatures.
Design Constraints
EV battery packs are engineered for maximum energy density, restricting available space for cooling systems. As a result, thermal materials must be thin, lightweight, and multifunctional – frequently serving as electrical insulators.
They must also endure extreme automotive conditions such as vibration, thermal cycling, and wide ambient temperature variations. Long-term stability depends on materials that resist cracking, drying, or pumping-out over time.
Objectives of Thermal Management
Thermal management aims to maintain all cell temperatures within a narrow temperature range (usually under 40 °C during normal operation), prevent local overheating, and contain heat in fault scenarios.
Achieving these targets requires thermal interfaces and spreaders to operate in tandem with active cooling systems, such as liquid cold plates or air channels.
Thermal Interface Pads (Gap Fillers)
Role and Function
Thermal interface materials (TIMs) fill microscopic air gaps between heat sources (cells) and cooling structures.
Since air has low thermal conductivity, even small voids can substantially increase resistance. Soft, conformable pads ensure intimate contact and continuous thermal pathways, enhancing heat transfer efficiency.
Common Materials
Most thermal pads are silicone elastomers infused with ceramic or graphite fillers, providing conductivities of 1 to 5 W/m K. Their high compressibility accommodates surface irregularities and dampens vibration.
Some pads exhibit phase-change behavior, softening or melting slightly under heat to improve interface contact and absorb transient heat spikes. Others maintain flexibility across wide temperature ranges.
Designing Custom Pads
Because every EV module has a unique geometry – such as prismatic, cylindrical, or pouch cells – custom-cut pads ensure optimal coverage and fit.
Precision die-cutting allows complex shapes with holes or cutouts to align with mounting features. Pad thickness must balance mechanical compliance with thermal performance: thicker pads fill larger gaps but increase thermal resistance. Combining a pad with a spacer may be preferred for gaps exceeding 5 mm.
Fast manufacturing and instant online pricing through platforms such as Materials Direct enable fast iteration, allowing for the testing of multiple pad designs within days.
Other Thermal Management Materials
Thermally Conductive Adhesive Tapes
Double-sided thermal tapes bond components during heat transfer. They’re popular for attaching sensors, spreaders, or heaters, as they eliminate messy adhesives and cure times.
Thermal Barriers for Runaway Protection
Some EV battery designs incorporate insulative barriers, such as mica sheets, ceramic fibers, or aerogel mats, between cell groups to slow the spread of heat during faults.
These barriers complement conductive materials by guiding heat toward cooling channels and preventing undesired transfer between cells.
Designing Custom Solutions and Prototyping
Tailoring to Module Geometry
The cooling requirements of each EV battery module differ. Standard pad sizes seldom fit perfectly, and manual cutting can lead to inconsistencies. Paired with digital die-cutting, CAD-based custom pad and spreader designs ensure accuracy and repeatability.
Quick-turn suppliers such as Materials Direct remove tooling expenses and deliver production-quality prototypes within 24 hours.
Rapid Iteration
Thermal testing and iteration are essential to optimization. The ability to quickly order variations (different conductivities, thicknesses, or materials) enables efficient design refinement.
Instant online quoting streamlines this process, ensuring projects stay on schedule even under demanding timelines.
Integration with Cooling Systems
Thermal pads and spreaders should be co-designed with active cooling components. Complete pad contact and consistent clamping pressure should be ensured for liquid cold plates.
Custom features, such as mounting holes or non-contact zones, can be incorporated directly into pad geometry for simplified assembly.
Get an Instant Quote for EV Battery Materials
Effective EV battery thermal management requires both material expertise and design agility. Custom thermal pads and heat spreaders, from silicone-based gap fillers to flexible graphite sheets, help maintain accurate temperature control, enhance uniformity, and improve safety.
Tailoring these components to each pack’s geometry guarantees optimal performance and minimized risk.
In the rapidly evolving EV industry, speed is paramount. Materials Direct offers instant online pricing and 24-hour production for custom-cut thermal materials. Whether the application calls for insulating pads or thermal tapes, quick-turn manufacturing enables rapid testing, validation, and solution implementation.
Partnering with Materials Direct ensures EV batteries run cooler, safer, and longer – because in electrification, thermal precision is essential for performance.
