High Quality Chromium-Molybdenum Alloy Steel Plate for Pressure Vessels and Industrial Boilers - ASTM/ ASME A387 Grade 5 Class 2

A387 Grade 5 Class 2 - high quality chromium-molybdenum alloy steel plate, ideal for use in pressure vessels and industrial boilers due to it's excellent heat resistant and anti corrosion properties. We can supply plates from our own stockholding in Birmingham or directly from the mill and all plates come with mill test certification and individual stamping

Different Grades of ASTM / ASME Grade 5 Chromium-Molybdenum Alloy

Masteel's range of ASTM / ASME A387 Grade 5 chromium-molybdenum alloy products are available in different grades listed in the following.

  • ASTM A387 Grade 5 Class 2
  • ASME SA387 Grade 5 Class 2

Equivalent Grade of A387 Grade 5 Chromium-Molybdenum Alloy

The equivalent grade of A387 Grade 5 chromium-molybdenum alloy is as follows:

BS

EN

ASTEM/ASME

DIN

-

-

A387-22-2

-

Chromium and Molybdenum Composition of A387 Grade 5 Chromium-Molybdenum Alloy

The chromium and molybdenum contents of A387 Grade 5 chromium-molybdenum alloy (according to the ASTM specification) are outlined in the following table.

Designation

Nominal Chromium Content (%)

Nominal Molybdenum Content (%)

A387 Grade 5

5.00%

0.50%

Tensile Requirements for A387 Grade 5 Chrome Molybdenum Class 2 Plates

The tensile requirements for A387 Grade 5 chromium-molybdenum alloy Class 2 Plates are listed in the following table.

Designation

Requirement

Grade 5

A387 Grade 5

Tensile strength, ksi [MPA]

75 to 100 [515 to 690]

Yield strength, min, ksi [MPa]/(0.2% offset)

45 [310]

Elongation in 8 in. [200mm], min %

-

Elongation in 2 in. [50mm], min, %

18

Reduction of area, min %

45 (measured on round specimen)
40 (measured on flat specifmen)

Chemical Composition of A387 Grade 5 Chromium-Molybdenum Alloy

The chemical composition of A387 Grade 5 chromium-molybdenum alloy from heat and product analysis is summarised in the following table.

Element

Analysis

Chemical Composition (%) inc. Grade & UNS No.

Grade 5 (UNS: S50200)

Carbon:

Heat Analysis:
Product Analysis:

0.15 max
0.15 max

Manganese:

Heat Analysis:
Product Analysis:

0.30 - 0.60
0.25 - 0.66

Phosphorus:

Heat Analysis:
Product Analysis:

0.035
0.035

Sulphur (max):

Heat Analysis:
Product Analysis:

0.030
0.030

Silicon:

Heat Analysis:
Product Analysis:

0.50 max
0.55 max

Chromium:

Heat Analysis:
Product Analysis:

4.00 - 6.00
3.90 - 6.10

Molybdenum:

Heat Analysis:
Product Analysis:

0.45 - 0.65
0.40 - 0.70

Tensile Test Requirements for Chromium-Molybdenum Alloy

The material shall be tested using a test specimen will confirm to the tensile requirements as outlined in tensile requirements for A387 Grade 5 chromium-molybdenum alloy Class 2 plates above.

Recommended Testing Procedures for Chromium-Molybdenum Alloy

The following requirements and testing procedures (which are not mandatory) are considered suitable for chromium-molybdenum alloy:

  • Vacuum treatment
  • Product Analysis
  • Additional Tension Test
  • Charpy V-Notch Impact Test
  • Drop Weight Test
  • High Temperature Tension Test
  • Ultrasonic Examination
  • Magnetic Particle Examination

To find out more about Masteel's services and ASTM A387 Grade 5 Class 2 steel plates which we can supply directly to you please visit Masteel.

This information has been sourced, reviewed and adapted from materials provided by Masteel UK Ltd.

For more information on this source, please visit Masteel UK Ltd.
