In high-reliability systems, like aerospace, defense, or medical devices, electromagnetic interference (EMI) presents a significant risk to performance and safety.
Image Credit: Irina Anosova/Shutterstock.com
Undesired electromagnetic noise can lead to data corruption, component malfunction, or system failure. By using conductive materials and design techniques, EMI shielding can block or contain electromagnetic fields, allowing sensitive electronics to coexist without interference.
This overview summarizes the most commonly used EMI shielding materials, from conventional metal enclosures to cutting-edge conductive elastomers and composites, and explores how they address the demanding requirements of mission-critical settings.
The Importance of EMI Shielding in Critical Systems
The Risk of Uncontrolled EMI
Even if EMI only causes a temporary glitch or background noise in consumer devices, it can have catastrophic consequences in mission-critical systems. Interference can originate from external sources (e.g., radio transmitters, lightning, or switching transients) or from other internal subsystems.
Without sufficient shielding, stray fields can disrupt logic signals or analog circuitry, resulting in faults or resets. As a result, regulatory bodies enforce stringent electromagnetic compatibility (EMC) testing as per MIL-STD-461, FCC, and CE requirements prior to deployment.
Shielding vs. Filtering
Shielding creates a physical barrier against electromagnetic fields, while filtering suppresses interference on power or signal lines. High-reliability designs usually integrate both techniques.
This article focuses on physical shielding materials, including conductive layers, gaskets, and housings, that prevent emissions or susceptibility.
Key Performance Metrics
Shielding effectiveness (SE) is quantified in decibels (dB), representing the attenuation of sound across a specific frequency range. High-reliability systems frequently require 60 to 100 dB of attenuation.
Other important metrics include electrical conductivity, mechanical durability, corrosion resistance, and compliance with outgassing or flammability standards. Materials used in aerospace or medical systems must maintain performance under vibration, extreme temperatures, and humidity.
Common EMI Shielding Materials and Solutions
Metal Enclosures and Foils
Metals, including aluminum, copper, steel, and nickel, are foundational EMI shields. These metals attenuate interference through reflection and absorption – free electrons within the metal oppose incident fields.
Aluminum alloys are commonly used in high-reliability systems due to their strength-to-weight ratio and broad-spectrum performance. EMI resistance can be significantly improved by incorporating a thin copper foil lining or metallized coating within a plastic enclosure.
However, there are limitations, including weight and limited flexibility, which require the use of lightweight gaskets and coatings.
Conductive Elastomers (Particle-Filled Silicones)
Conductive elastomers combine the conductivity of metals with the resilience of silicone rubber. Filled with particles including silver-plated aluminum, nickel-graphite, or carbon, they form EMI gaskets that seal joints, doors, or panels.
These materials preserve contact integrity under vibration and thermal cycling, a crucial metric for aerospace and defense equipment. For example, nickel-graphite silicones provide corrosion resistance and cost advantages while satisfying military shielding requirements.
Typical attenuation ranges from 70 to 110 dB, depending on frequency and compression.
EMI Shielding Tapes and Laminates
Flexible polymer tapes reinforced with conductive foil or fabric provide a lightweight, fast-shielding solution. Their adhesive backing frequently includes conductive fillers to ensure electrical continuity. These materials are well-suited for cable wraps or temporary fixes during prototyping; however, permanent assemblies typically rely on gaskets or coated enclosures for consistency.
Selecting Materials for High-Reliability Applications
Environmental Durability
In mission-critical applications, shielding materials must withstand a wide range of temperatures, vibration, and chemical exposure.
For example, in outdoor or marine applications, corrosion resistance is critical; nickel- or carbon-filled elastomers often outperform silver in such conditions. However, gasket durability depends on both particle orientation and composition. Silver- or copper-based elastomer shielding can be appropriate for these demanding conditions.
Conductivity and Shielding Effectiveness
SE is directly impacted by material conductivity. A continuous aluminum shell can achieve an attenuation of over 100 dB, whereas plated plastics might achieve 40 to 70 dB. SE curves from manufacturers should be interpreted to match materials to system frequency bands.
In hybrid solutions, the overall performance is determined by the weakest interface; flat mating surfaces and consistent gasket compression are just as important as choosing a high-performance material.
Weight and Geometry Constraints
Minimizing mass plays a critical role in aerospace and portable systems. Conductive composites, carbon-fiber laminates, and plated polymers significantly reduce weight. These materials must also endure mechanical stress and thermal expansion.
Sophisticated layups incorporate metal foil layers into composites to achieve superior EMI control without excessive mass.
Assembly and Maintainability
Designers must take serviceability into account. Field-replaceable gaskets or clip-in shield covers facilitate maintenance much more easily than glued form-in-place solutions.
For high-reliability programs with frequent inspection or maintenance cycles, replaceable shielding is preferred. Materials Direct provides custom-cut gaskets and shield components for these applications – produced within 24 hours to support rapid design iteration.
Emerging Materials and Trends
Multi-Functional Materials
Materials that integrate both EMI and thermal management are gaining popularity. For instance, thermally conductive silicone gaskets can simultaneously dissipate heat and block electromagnetic fields, which is ideal for high-power, compact electronics.
Rapid Prototyping and Customization
Today’s EMC design cycles prioritize speed. Rapid production of conductive foams, elastomer sheets, and precision-cut gaskets enables early testing of EMI mitigation.
Materials Direct’s instant online quoting and 24-hour production capabilities support fast procurement of shielding components, accelerating compliance confirmation.
Looking for EMI Shielding Materials?
Electromagnetic interference poses a serious challenge to mission-critical electronics. Whether using conventional metals, cutting-edge elastomers, or emerging nanocomposites, engineers must consider shielding effectiveness, durability, and environmental compatibility. An optimized EMI control strategy combines multiple materials and methods tailored to specific system requirements.
To achieve compliance efficiently, teams benefit from working with suppliers that can provide high-precision shielding components quickly. Materials Direct delivers rapid-turn production of custom EMI gaskets, conductive films, and technical materials, offering instant online pricing and 24-hour delivery.
With the appropriate materials and the ability to iterate quickly, high-reliability systems can perform flawlessly even under the most demanding electromagnetic conditions.
