Nickel Filled Electrically Conductive - Adhesives, Sealants and Coatings

Master Bond offers a wide variety of nickel filled electrically conductive adhesives. Both one and two component systems are available for use. These compounds provide a more cost effective solution than silver filled grades for applications that require electrical conductivity and low volume resistivity. They also have outstanding resistance to water and chemicals.

The superior performance profile of our electrically conductive compounds is widely recognized throughout the electronics industry. The cured products offer high physical strength, superior substrate adhesion and uniform electrical conductivity even upon exposure to hostile environmental conditions. Long term durability is excellent. Special grades are vibration and shock resistant, cryogenically serviceable, “snap curing”, offer exceptional peel and shear strength and are screen printable.

Major Applications

Master Bond nickel filled electrically conductive adhesives offer high physical strength, superior substrate adhesion and uniform conductivity even upon exposure to hostile environmental conditions. Long term durability is excellent. Common applications include:

  • Electrical modules
  • PCBs
  • High frequency shields
  • Wave guides
  • EMI/RFI shielding
  • Entertainment systems
  • Specialty heat sinks
  • Interconnection repair
  • Digital signal processors
  • Solar cell manufacturing
  • Electrical ground plane interface
  • RFID tagging
  • Printed wiring board applications
  • LED packaging
  • Wireless headsets
  • Wafer lamination
  • Stack bonding
  • Copper/polymide (PI) circuits
  • Integrated circuitry
  • Flip chip packaging
  • Thermistors
  • Microprocessors
  • Stress control devices
  • Wire tacking
  • SMD attachment
  • Hermetic lid-seal processes
  • Communication systems
  • Electronic test equipment
  • Hybrid microelectronic packaging
  • Membrane switches
  • Antenna assemblies

Popular Electrically Conductive Nickel Polymer Systems

Some of the popular electrically conductive nickel polymer systems include:

EP76M

Master Bond's EP76M is a two component, nickel filled, electrically conductive adhesive for high performance bonding, sealing, and coating. Formulated to cure at room temperature or more rapidly at elevated temperatures. Adaptable to thermal cycling and resistant to many chemicals.

EP21TDCNFL

EP21TDCNFL is a two component, nickel filled, electrically conductive system with high flexibility and elongation. Serviceable over wide temperature range of 4K to +250°F.

Supreme 10HTFN

Supreme 10HTFN is a one component, no mix, nickel conductive system with high shear and peel strength. Cures in as little as 2 minutes at 380 -400°F. Superior resistance to impact, thermal shock, vibration and stress fatigue cracking. Serviceable from 4K to 400° F.

X5N

X5N is a cost effective, one component nickel conductive elastomer adhesive, sealant and coating for EMl/RFI shielding. Superior shielding over a wide frequency range and excellent environmental resistance.

Basic Requirements

Master Bond's electrically conductive adhesive systems are designed to meet specific performance requirements. Specific grades offer a wide range of properties, among the most important are:

  • Chemical resistance
  • Cryogenic serviceability
  • Excellent adhesion to similar and dissimilar substrates
  • Dimensional stability
  • High temperature resistance
  • Low coefficient of thermal Expansion
  • Reworkable
  • Screen printable
  • Range of hardness
  • Low outgassing
  • Low shrinkage
  • Low stress
  • Resistance to water
  • Peel strength
  • Durability
  • Thermal cycling resistant
  • Shock resistance
  • Impact resistance
  • High electrical conductivity
  • Thermal conductivity
  • Vibration resistance
  • Low volume resistivity
  • High glass transition temperature
  • Compressive strength
  • Tensile strength
  • Elongation
  • Flexural strength

Master Bond Polymer Adhesive EP76M

Master Bond Polymer System EP76M is a two component, nickel filled, electrically conductive adhesive for high performance bonding, sealing, and coating formulated to cure at room temperature or more rapidly at elevated temperatures. Unlike the majority of two part nickel conductive systems, EP76M has a one-to-one mix ratio by weight or volume. It readily develops a high bonding strength of more than 2000 psi tensile shear strength when measured and cured at 75°F. It is 100% reactive and does not contain any diluents or solvents. The volume resistivity of the cured system is 5-10 ohm-cm.

Master Bond Polymer System EP76M can be applied with minimal sagging or dripping even on vertical surfaces, although it can be made thinner (flowable) by adding 5 to 10% of an appropriate solvent (xylene, acetone, MEK, etc.) by weight. The high strength bonds are remarkably adaptable to thermal cycling and resistant to chemicals including water, oil and most organic solvents over the exceptionally wide temperature range of -60°F to more than +250°F. Adhesion to metals, glass, ceramics, vulcanized rubbers and many plastics is excellent. Parts A and B are both colored gray. Master Bond EP76M adhesive is widely used in the electronic, electrical, computer, semiconductor, microwave, appliance and automotive industries among others. There are also are a number of specialized versions of EP76M available. These include EP76 which meets certain military specs, EP76M-F which is a fast curing version (5-10 minute set up time), and EP76MHT which is a high temperature resistant version (serviceable up to 400°F).

Packaging

Our electrically conductive products consist of one and two part epoxies. They are conveniently packaged for ease of use. They are available in syringes, jars, bubble packs, cartridges, etc. Two component systems can be purchased in premixed, frozen syringes. Freshly prepared to maximize shelf life, Master Bond electrically conductive compounds can be bought in quantities from grams to gallons.

This information has been sourced, reviewed and adapted from materials provided by Master Bond Inc.

For more information on this source, please visit Master Bond Inc.
