LED Curable Adhesive System LED401

Rapid curing, one component, no mix Master Bond LED401 offers high optical clarity and excellent physical strength properties. It cures fully upon exposure to Active 405 nm wavelength light source. It can cure in sections up to 1/8 inch thick. Environmentally friendly LED401 contains no solvents or volatiles. It cures tack-free without any oxygen inhibition.

LED, Curable Adhesive, LED401, Adhesive

Advantages of LED401 Adhesive

  • Ideal for bonding thermally sensitive parts- limited heat/IR emitted
  • Adhesion to a wide variety of substrates – including tinted and UV blocked materials
  • High bond strength to glass, metals, elastomers and many plastics including polycarbonates and acrylics
  • Full cures can be achieved in 15-30 seconds in thin sections
  • Lower processing costs

Master Bond LED401 has a viscosity of 100,000-150,000 cps – a high viscosity but flowable. It has superior dimensional stability and superb electrical insulation properties. Resistance to moisture and many chemicals is outstanding. It has a Shore D hardness >65-70 and a glass transition temperature of 70-75°C.

LED light sources are considered less hazardous and more user-friendly than their UV counterparts. Speed of cure is dependent upon the intensity of the light source, the thickness of the layer and the distance of the light from the material being cured. LED401 is available for use in convenient syringe applicators and in 1/2 pint, pint, quart, gallon and 5 gallon units. Its shelf life in original unopened containers is 6 months. Additional LED curable systems available for use include LED401LV (low viscosity LED curable compound) and LED403Med (medical grade, USP Class VI approved; also passes ISO 10993-5 cytotoxicity test).

Cutting Edge Formulations

The Master bond product line consists of advanced epoxies, silicones, polyurethanes, polysulfides, UV/LED cures and other specialty systems. Each compound is designed to meet specific application requirements. Master Bond’s environmentally friendly systems are available in convenient packaging from small to large sizes.

Outstanding Technical Support

With years of experience in technical support, the Master Bond team will be able to assess your application and recommend the most suitable polymer system to meet your specifications. Master Bond will continue to guide you throughout the design, prototype and manufacturing process. Master Bond offers replacements for discontinued products.

Latest Technological Advancements

As a worldwide manufacturer of polymer compounds, Master Bond is continuously working with universities and R&D labs to improve product performance. Master Bond products are designed to maximize productivity, reduce waste, save energy and for dependable, long term durability.
