With electronics getting smaller and smaller the demands on semiconductor manufacturers are increasing. To ensure the quality and consistency of substrates, wafer manufacturers employ metrology tools to control the quaility of their materials. Metrology tools for the semiconductor industry may include a variety of technologies and instruments such as wafer probes, AFMs, SEMs, profilometers and ellipsometers.
If you'd like us to help you source a Quotation for Semiconductor/Wafer Metrology Tools please click here. Once submitted, we will try and place you in contact with a suitable Semiconductor/Wafer Metrology Tools supplier within 48 hours.
Featured Equipment
Semilab has developed research and development tools for a wide range of applications in semiconductor, material sciences, and photovoltaic research.
Other Equipment
Olympus' MX61L/ MX61 semiconductor inspection microscope offers excellent clarity and image resolution using observation techniques such as infrared, fluorescence, differential interference contrast (DIC), dark-field and bright-field. It consists of specially designed IR objective lenses for imaging defects below the glass/silicon surface.
CAMECA's new generation Shallow Probe: the metrology solution for advanced integration of new processes.
The TriPhemos Time-Resolved Imaging Emission Microscope is suitable for analyzing the circuit timing by detecting the faint light which is generated when CMOS transistors operate using a two-dimensional infrared detector, thus analyzing the device timing with picosecond precision.
Hamamatsu offers the IR-OBIRCH Analysis System which is a semiconductor failure analyzer.
MTI Instruments offers Proforma 300SA, a semi-automated metrology system employed in thickness measurement for semi-insulating and semiconducting wafer materials.
PVS-5000 from Semilab is a high throughput PV wafer inspection and sorting system. The PVS-5000 is field proven and integrates high reliability wafer handling with PV metrology to enable a turnkey solution for incoming wafer sorting.
Imina Technologies has introduced miBot™ BT-11, a mobile micro-robot designed to perform different manipulation, sensing and positioning tasks at micro and nano scales.
Mahr’s MarVision video workshop measuring microscope QM 300 with M3 software is a tool that is capable of measuring and/or determining geometric elements such as lines, points, distances, intersection, and circles through automatic edge detection.
Hamamatsu offers the iPhemos-SD Inverted Emission Microscope which is suitable for docking with different types of testers.
The Proforma 300i wafer metrology system supplied by MTI Instruments is a manual, non-contact measurement system designed to measure wafers up to 300mm in diameter for both thickness and total thickness variation (TTV).
The Phemos-200 developed by Hamamatsu is an emission microscope which consists of a high-resolution, cooled CCD camera with a pixel of about 1024×1024.
Mahr’s MarVision workshop measuring microscope MM 320 with M3 software is designed to handle measurement of electronic parts such as printed circuit boards, small features on micromechanical parts, 2D profile measurements on plastic and metal parts, and production control of turned components.
The NPFLEX™ 3D Surface Metrology System from Bruker offers high flexibility, measurement capabilities, and superior performance to precision manufacturing industries, ensuring rapid ramp-up times, excellent product quality and improved productivity.
Semi-automated wafer characterization system for determining wafer thickness, TTV, bow warp, site and global flatness measurement. The Proforma 300SA can be used for all wafer materials and accommodates 200mm and 300mm wafer diameters.
MicroSense has launched an advanced sapphire wafer metrology system that is capable of measuring sapphire wafers with any surface finish with high repeatability and high throughput.
The UltraMap 200-BP is a flexible wafer measurement system that is capable of measuring wafer thickness, shape and flatness using MicroSense's patented non-contact auto-probe back pressure technology.
PCB manufacturers are developing denser and small features on highly thin high-density interconnect (HDI) and multi-chip module (MCM) substrates.
Mahr’s Pocket Surf portable surface roughness gage is a low-cost tool that is designed exclusively to handle traceable surface roughness measurements on numerous types of surfaces.
THEMOS mini is a thermal emission microscope which is designed by Hamamatsu. It is suitable for indicating the occurrence of failures in the semiconductor device by displaying the detected thermal image superimposed onto the pattern image.
Bruker’s LumiMap Electroluminescence System is a reliable and accurate metrology system and designed for HB-LED epitaxial inspection for R&D and production.
This sophisticated, flexible wafer metrology system combines a MicroEpsilon profilometer with a high-performance, high-resolution vision system and laser interferometers to detect and measure laser-cut features on one side of a wafer relative to features on the other side of the wafer.
The DektakXT™ Stylus Profiler from Bruker has an innovative design enabling a consistency better than 4Å.The key milestone in the performance of the stylus profiler is due to 40 years of Dektak® innovation and industry leadership.
