Analyzing NOx in Exhaust Emissions with FT-IR Spectroscopy

Shutterstock | Orlando_Stocker

Image Credit: Orlando_Stocker/

NOx emissions and air pollution from diesel engines are a global concern because of their potential effects on human health. Researchers all over the world are developing new and improved methods to lower NOx emissions. Infrared spectroscopy in the gas phase, which is made possible using Specac’s gas cells, plays a key role in this research.

It is estimated that every year, three million people die prematurely due to outdoor air pollution. Diseases and deaths caused by air pollution are becoming a worldwide public health concern. Due to these concerns, the World Health Organization has published guidance on limits and thresholds for main air pollutants that pose health risks. The pollutants included in the guidance are sulfur dioxide, nitrogen oxides (NOx), ozone, and particulate matter.

NOx Emissions are a Public Health Hazard

Diesel engines lower CO2 emissions and provide a better fuel economy than conventional gasoline engines, and hence were once considered as the ‘greener’ alternative. However, in recent years, the image of diesel as a ‘green fuel’ has been shattered by the revelation that diesel engines give out more harmful pollutants than their gasoline counterparts.

Diesel engines work at a higher pressure and temperature than gasoline engines, which favors the production of NOx gases. Therefore, diesel engines produce more NOx emissions than gasoline engines. Exposure to NOx emissions has been associated with increased deaths from lung disease, heart disease, and other respiratory illnesses. NOx emissions also lead to the formation of environmental phenomena like acid rain and smog.

In an attempt to reduce air pollution and improve air quality, many countries are now trying to decrease the number of diesel cars on their roads. However, the uses of diesel fuels are not limited to cars alone. The higher efficiency and density of diesel fuel along with its slower combustion characteristics make diesel a better alternative to gasoline for the larger vehicles used in freight and transportation. Most buses, trucks, tractors, and military vehicles use diesel, in addition to many ships and trains. Industry, general combustion, and stationary diesel engines also considerably contribute to NOx emissions.

As diesel engines are more prevalent, removing all diesel engines is not a realistic goal. Instead, scientists worldwide have been developing ways to decrease the NO2x emissions produced by diesel engines.

Reducing NOx Emissions from Diesel Engines

The production of NOx emissions by gasoline engines are reduced using a three-way catalyst. However, these catalysts can’t be employed for diesel engines as diesel exhaust gases usually contain oxygen, which causes the three-way catalyst to be inactive. The leading method used in removal of NOx from diesel engine exhaust gases is selective catalytic reduction (SCR). SCR reduces NOx to water and nitrogen with the help of a reducing agent, usually ammonia, in the presence of a catalyst.

Ammonia-SCR is broadly used for industrial NOx emissions and stationary diesel engines. SCR has several advantages, including a NOx conversion rate of 90%. However, SCR systems are expensive, large, and can generate ammonia emissions, making them unsuitable for mobile NOx reduction processes.

In recent days, urea-SCR has been highlighted as a potential alternative to ammonia-SCR for mobile diesel engines. In urea-SCR, the urea is broken down to form ammonia before the SCR reaction occurs. Similar to ammonia-SCR, urea-SCR can provide 90% NOx conversion, but also provides a greater durability, wider temperature operating window, lower costs, and lower emissions. However, applications of urea-SCR still have limitations like insufficient catalyst optimization, urea dosing technology and under-developed urea infrastructures.

Studying NOx Reduction with FT-IR

Fourier transform infrared (FT-IR) spectroscopy can offer a suitable means to track the presence of gases in diesel exhaust emissions. FT-IR spectroscopy involves shining an infrared beam on a reaction or sample. Molecules absorb infrared light at specific wavelengths depending on their chemical structure, providing a molecular ‘fingerprint’. In this way, FT-IR can be used to monitor the progress of the NOx reduction reaction and molecules present in exhaust fumes. A recent study by scientists from the Technical University of Freiberg, Germany, used FTIR to track the presence of N2O, NO, NO2, NH3, HNCO, and H2O in diesel exhaust fumes that were treated using urea and ammonia SCR.

FT-IR can also be used to give more comprehensive insights about the SCR catalyst and the progress of the SCR reaction by performing FT-IR spectroscopy on the catalyst bed during the reaction (in-situ). Molecules interact with the catalyst surface, and so the molecular fingerprint observed by FTIR is slightly changed and can give important details about how reactants, products, poisons, and intermediates interact with the catalyst. If these interactions are understood, it can be useful for intelligently designing new, improved catalysts for both urea and ammonia -SCR.

Studying NOx reduction reactions using infrared spectroscopy needs accurate and reliable equipment. Specac provides a range of accessories for infrared spectroscopy that are perfect for studying gaseous catalysis chemistry.

Specac’s gas cells which are designed for transmission FT-IR experiments can be used to offer quantitative analysis of the SCR exit gases composition. The diffuse reflectance accessory and selector environmental chamber provide the ideal solution for studying SCR catalysts and reactions in situ. The Selector cell can be heated to 800 °C and powder or solid SCR catalyst samples can be placed onto a sampling cup within an atmospherically controllable chamber for spectroscopic analysis.

To sum up, it is a worldwide important problem to reduce NOx emissions from diesel engines. The current research is focused on enhancing and modifying SCR reactions for mobile diesel engines. FTIR plays an important role in the development of new SCR catalysts and processes.

References and Further Reading

  1. ‘The contribution of outdoor air pollution sources to premature mortality on a global scale’ J. Lelieveld, J. S. Evans, M. Fnais, D. Giannadaki, A. Pozzer, Nature, 2015.
  2. ‘Air pollution and health’
  3. ‘Ambient (outdoor) air quality and health’
  4. ‘A Review on Selective Catalytic Reduction of NOx by NH3 over Mn–Based Catalysts at Low Temperatures: Catalysts, Mechanisms, Kinetics and DFT Calculations’ F Gao, X. Tang, Ho. Yi, S. Zhao, C. Li, J. Li, Y. Shi, X. Meng, Catalysts, 2017.
  5. ‘NOx Storage and Reduction for Diesel Engine Exhaust Aftertreatment’ in ‘Diesel Engine - Combustion, Emissions and Condition Monitoring, B. Pereda-Ayo, J.R. González-Velasco, InTech, 2013.
  6. ‘Diesel catalysts’
  7. ‘An FT-IR study of the adsorption of urea and ammonia over V2O5–MoO3–TiO2 SCR catalysts’ M.A. Larrubia, G. Ramis, G. Busca, Applied Catalysis B: Environmental, 2000.
  8. ‘Urea Decomposition in Selective Catalytic Reduction on V2O5/WO3/TiO2 Catalyst in Diesel Exhaust’ M. Goldbach, A. Roppertz, P. Langenfeld, M. Wackerhagen, S. Füger, S. Kureti, Chemical Engineering & Technology, 2017.
  9. ‘FTIR accessories’
