The Best Convertibles Solutions for Furnaces

The Deltech products that you may not be fully aware of are their convertible furnaces.

Suppose the scenario depends on colleagues planning on sharing furnace time, but one party requires a controlled atmosphere tube design and they want a bottom loader: it really is possible to have it all with a CVT/BL or CHT/BL model or even a CVTHT/Bl model that facilitates vertical or horizontal orientation of the tube. Effectively two Furnaces for the Price of One!

Here is how it works: starting with a bottom load furnace which may include an electric or a pneumatic lift, both of which offer smooth operation. While the pneumatic requires a 100-psi air supply and features variable-rate functionality, the travel rate of the electric lift is fixed.

Ask us for advice about which option is most well-suited for your needs. Once the appropriate lift has been selected, the relative tube openings are made in the top and bottom or sides or both.

Exceptionally hard-wearing plugs are provided for positioning in the openings as necessary. The plug heads will remain flush with the furnace exterior making them easy to grasp when being placed or removed.

What is more, Deltech supplies a tube furnace that can operate in either a vertical or horizontal orientation. For lower temperature furnaces (1200 degrees Celsius), a mechanism facilitates rotation of the furnace across various orientations.

For furnaces that utilize silicon carbide (up to 1500 degrees Celsius operating temperatures) and molydisilicide heating elements (1600-1800 degrees Celsius), Deltech initially offers a horizontal tube furnace and then provides the requisite openings and durable plugs; this allows the unit to function with a tube positioned vertically.

Finally, if a tube furnace requires process tubes in alternate sizes (outer diameter) for various projects. Deltech manufactures the controlled atmosphere furnace for use with the biggest diameter tube and also offers hard-wearing plugs complete with center openings for use with smaller tubes.

So if all-round flexibility is what you need, let Deltech help you decide on the optimum convertibles solution for any situation and process requirements.

This information has been sourced, reviewed and adapted from materials provided by Deltech, Inc.

For more information on this source, please visit Deltech, Inc.
