Fluoropolymer Material Solution - Rulon® J

The Rulon® J fluoropolymer material solution is ideal for soft shaft, low friction, and extreme cold temperature. The wear and friction control material is suitable for high-speed, low-load applications as it has one of the lowest coefficients of friction among the blended PTFE materials available in the market. Common critical components include consumer glide rings (bicycle suspension systems), industrial arm wear pads (production compressors), and mass transportation sliding elements (train bogies).

. .
Material Gold fluoropolymer
Engineered polymer filled
Service Conditions Temperature: -269 to +315 °C
Max load (dry): 5.5 MPa
Max Speed: 2 m/s
Feature Friction coefficient: 0.12 to 0.20
Max PV (dry/lub): 0.26 MPa.m/s
Dimension Rods and Tubes: (φ) 1.2 m x (L) 3 m
Sheets: (L,W) 610 mm x (T) 80 mm
Tapes: (W) 1 mx (T)=[0.08;6] mm



Options

The following options can be added to the product:

  • Vacuum and UHV
  • Abrasion-resistant
  • Load upgrade
  • Noise reduction
  • FDA approved
