Two Component Epoxy Adhesive EP31 Offers Outstanding Flexural Strength Properties

Recently, I recommended this product for an aerospace application where the shear and flexural strength requirements were very high. In the prototype phase, the customer tried a heat curing epoxy, but, their new design involved much larger parts. Therefore, the use of an oven for heating the epoxy was not possible. EP31 not only met their strength requirements, but, it also eliminated the need for an oven since it is a room temperature curing system.

Venkat Nandivada, Master Bond Technical Advisor

Room temperature curing Master Bond EP31 epoxy adhesive is designed for high performance structural bonding. It has a lap shear strength of 4,600 psi and a peel strength of > 40 pli. It also features a flexural strength of 13,200 psi. EP31 is resistant to exposure to many chemicals, including oils and fuels. The cured adhesive is a superb electrical insulator. Shrinkage upon cure is extremely low.

Master Bond EP31 has a 100 to 30 max ratio by weight. Working life for a 100 gram mass after mixing is > 30 minutes. It has a Shore D hardness of > 75. Its service operating temperature range is -60°F to +250°F. EP31 contains no solvents or volatiles. Adhesion to metals, ceramics, glass, rubbers and most plastics is excellent. It is easy to apply. A non-drip version called EP31ND is also available for use.

Master Bond Has developed numerous one and two component epoxy systems for high flexural strength applications. These compounds have superior thermal stability, exceptional chemical resistance and outstanding bond strength. They provide cost effective solutions to many challenging requirements. Manufacturing companies rely on these compounds to meet demanding needs in critical applications.

Cutting Edge Formulations

The Master Bond product line consists of advanced epoxies, silicones, polyurethanes, polysulfides, UV/LED cures and other specialty systems. Each compound is designed to meet specific application requirements. Master Bond environmentally friendly systems are available in convenient packaging from small to large sizes.

Outstanding Technical Support

With years of experience in technical support, the Master Bond team will be able to assess your application and recommend the most suitable polymer system to meet your specifications. Master Bond will continue to guide you throughout the design, prototype and manufacturing process. Master Bond offers replacements for discontinued products.

Latest Technological Advancements

As a worldwide manufacturer of polymer compounds, Master Bond is continuously working with universities and R&D labs to improve product performance. Master Bond products are designed to maximize productivity, reduce waste, save energy and for dependable, long term durability.

This information has been sourced, reviewed and adapted from materials provided by Master Bond Inc.

For more information on this source, please visit Master Bond Inc.
