Invar - Nickel Iron Alloy

Chemical Formula

Ni-Fe Alloy

Image Credit: RHJPhtotos/

Topics Covered


Discovery and Nobel Prize

Physical Poperties

Current Uses

Cathode Ray Tubes

Other Applications

Low Expansion Alloys

Sealing Alloys

Future Uses

Composite Manufacturing



Few people realise that the nickel-iron alloy, Invar, plays a crucial part in so many of their household controls and office appliances. This role was established soon after its discovery 100 years ago in 1896. Invar is the forerunner of a family of controlled expansion nickel-iron alloys which form the essential part of bimetals and thermostats. Invar itself is still used today in vast numbers of household appliances, from electric irons and toasters to gas cookers and fire safety cutoffs. In the office, computer terminals and TV screens make extensive use of Invar and other Ni-Fe alloys for shadow masks, frames, and cathode ray tube gun parts.

Other applications for these special alloys are continuing to be found in industry for advanced electronic components, filters in mobile phone networks and even as tank membranes for massive liquefied natural gas transport ships.

Discovery and Nobel PrizeAnchor

When Invar was discovered in 1896, its unique property of low and linear expansion over a wide temperature range allowed the production of effective bimetals which could be used in safety cut-off devices for gas cookers and heaters. For his work on the nickel-iron system and the discovery of Invar, Charles Edouard Guillaume of Imphy was awarded a Nobel prize for Physics early in the 20th century.

One of the traditional uses for Invar has been for the thermostat of electric immersion heaters, used for a variety of domestic and commercial water heating systems. Operation of the thermostat is based upon differential expansion between a brass tube and an inner Invar rod, with the resulting movement being used to actuate a microswitch. The set temperature is commonly adjustable in the range between 48-83°C.

Invar PropertiesAnchor

Invar is a 36% nickel-iron alloy which has the lowest thermal expansion among all metals and alloys in the range from room temperature up to approximately 230°C. The controlled expansion alloy is ductile and easily weldable, and machinability is similar to austenitic stainless steel. It does not suffer from stress corrosion cracking.

The mean coefficient of thermal expansion (CTE) of Invar from 20-100°C is less than 1.3 x 10-6°C-1. The Curie point is 230°C, and density is 8100 kg.m-3.

Current Uses Anchor

Cathode Ray TubesAnchor

Between the range -100 to +200°C Invar's CTE is very low. This feature is very useful for many specific applications in high tech industry. Cathode ray tubes for television and display screens are increasingly required to provide greater user comfort, with higher contrast, improved brightness and sharper definition. This progress has been made possible by the use of shadow masks made from Invar strip, with its low coefficient of thermal expansion allowing precise dimensioning of components even with changing temperature.

Other ApplicationsAnchor

Other application areas, such as telecommunications, aeronautical and aerospace engineering, cryogenic engineering (liquefied natural gas tankers) etc, require either high dimensional stability with variation in temperature, or expansion characteristics matched with those of other materials, such as glass, ceramics, or composites.

The diversity of these requirements has led to the development of a wide range of Fe-Ni, Fe-Ni-Co and Fe-Ni-Cr alloys, in two major groups:

Low Expansion AlloysAnchor

Invar alloys include Invar and N42. As electronic components become ever more miniature, the demands on the material used in their manufacture become ever more critical. The production of lead frames for example requires very close dimensional tolerances and high cleanliness combined with exceptional stamping or chemical etching performance. Grades of N42 have been specifically developed to match these requirements.

Sealing AlloysAnchor

These include other Fe-Ni grades, Fe-Ni-Co and Fe-Ni-Cr alloys. A full range of invar alloys have been produced to associate with the principal glasses supplied by major manufacturers including Schott, Corning, NEG and Ashai. These glasses used in electronics are chosen for specific physical, chemical or optical properties and the choice of the associated sealing metal depends on the glass and the type of seal (matched or compressive).

Future UsesAnchor

Appropriate solutions are needed to match the requirements created by technologies which are in rapid and perpetual evolution, and these could come from Invar and its derivatives.

Composite ManufacturingAnchor

Invar also has an important role to play in the future of composite manufacturing. The aerospace industry will make increasing use of composites for weight/strength improvements. The manufacturing process of composite multilayer structures involves moulding on tools which are then autoclaved. Tooling materials must provide temperature resistance, very low CTE to match the composite, vacuum integrity, thermal conductivity and machinability.

A single tooling material to meet all the requirements does not exist, but of all metallic and non-metallic (e.g. carbon fibre/epoxy) options, Invar provides one of the lowest CTEs of all, the major criterion. The compatibility of the CTE of the Invar mould and the composite parts avoids distortion, induced stress and warpage. Studies carried out by Boeing show that Invar is the material which will provide the best compromise between the most important requirements (like CTE and durability) and overall fabrication costs.

More from AZoM: Dehydration of Hexahydrate Nickel Sulfate


Primary author: Colin Woolger

Source: Materials World, Vol.  No. pp. 332-33, June 1996.
