ABB Utilizes BASF Flame-Retardant PBT for DC Contactors in Railway Applications

The company ABB in Lyon has recently started to use the polybutylene terephthalate (PBT) Ultradur® B4450 G5 from BASF for its DC contactors. Since these contactors are used on railways, they must satisfy the stringent fire prevention requirements of the French Railway Standard NF F 16-101.

The 25 % glass fiber-reinforced thermoplastic is based on a special flame retardant system and, with its especially good values for smoke density and toxicity, satisfies the requirements for the I3F2 classification in this standard. This material has found one of its first production applications at ABB. It is available in light colors and exhibits good processability and mechanical properties.

DC contactors from ABB, Lyon, that are used in railway applications represent one of the first production applications of the engineering thermoplastic Ultradur® B4450 G5. For this, they had to satisfy the requirements of the French Railway Standard NF F 16-101. The glass fiber-reinforced PBT material from BASF is flame-retardant, available in light colors, has a low smoke density/toxicity and, with a CTI of 600, provides high tracking resistance. Photo: BASF - The Chemical Company, 2013

A special property of the material is that installed metal contacts display only minimal corrosion even in warm environment with high humidity. As a result, electrical components that come into contact with this plastic benefit in terms of reliability and appearance. With regard to electrical properties, the material has a CTI value of 600. This means that Ultradur B4450 G5 exhibits a tracking resistance, or insulating ability, that is exceptionally good for PBT compounds and in turn provides a great deal of freedom, especially regarding component miniaturization.

The laser contrast of Ultradur® B4450 G5 is also good in the case of light colors and makes it possible to incorporate engraved identification such as data matrix codes that can be read with a scanner. In addition to contactors, the flame-retardant material is suitable for use in other current-carrying electrical components where dimensional stability is critical, for instance, in micro circuit breakers used in photovoltaic systems, power electronics housings or coil bodies.

www.ultradur.de

Additional information on Ultradur® (PBT) materials from BASF is available by sending an e-mail to the address [email protected] or calling the telephone number +49 (0) 621 60 78780

Source: http://www.basf.com/
