Advancing Geopolymer Composites with Water-Soluble Polymers

In a recent article in Materials, US researchers investigated the impact of water-soluble polymers on the rheology and microstructure of polymer-modified geopolymer glass ceramics. The incorporation of all-aromatic polyelectrolyte reinforcements aims to enhance the properties of geopolymer composites, offering potential advancements in materials science and engineering.

Advancing Geopolymer Composites with Water-Soluble Polymers

Image Credit: Gorodenkoff/


Geopolymer materials have gained significant attention in recent years due to their unique properties and potential applications in various industries, including construction, aerospace, and environmental remediation. These inorganic polymers offer advantages such as high strength, chemical resistance, and low environmental impact compared to traditional cement-based materials.

To fully harness the benefits of geopolymer composites, optimizing their properties through innovative approaches is essential. One promising strategy is incorporating water-soluble, high-performance polymers. This study addresses the growing demand for advanced materials with improved performance characteristics and tailored properties.

The Current Study

The rheological properties of the geopolymer resins were analyzed with a forced convection oven under airflow. The experiments were conducted in quadruplicate at 25 °C. To maintain humidity and prevent water loss during sample collection, a moist wipe was added to the bottom of the oven.

Stainless steel parallel plates, each with a diameter of 25 mm, were employed to minimize particle-geometry interactions and provide adequate torque sensitivity over a broad range of viscosities. Before testing, all samples underwent a pre-shearing process to standardize the sample loading. Both oscillatory and steady shear procedures were employed to assess the rheological behavior of the geopolymer resins.

The final incorporation of PBDT and PBDI into the geopolymer composites was quantified by Thermal Gravimetric Analysis (TGA). Geopolymer samples were crushed into fine powder (<10 µm) and loaded onto flame-dried platinum pans. Samples were heated from room temperature to 200 °C and stabilized for 30 minutes to remove physiosorbed water.

The samples were then brought to 50 °C and heated to 1000 °C, and the mass loss due to water was accounted for in the analysis. All experiments were performed in triplicate to ensure reproducibility and accuracy of the results.

For Scanning Electron Microscopy (SEM) analysis, a surface area of approximately 2 cm² on geopolymer plaques was prepared. Initially, a silicon carbide (SiC) polish removed the upper surface of the geopolymer plaque. Subsequent polishing steps utilized a series of fine grit selections, including nylon pads and diamond polishing pastes, until the sample surface reached a tolerance of approximately 1 µm.

Non-aqueous solvents were used during the polishing process to prevent any loss of the sample material. The prepared samples were then subjected to SEM analysis to investigate the microstructure and surface morphology of the geopolymer composites.

Results and Discussion

The rheological analysis of the geopolymer resins revealed significant changes in viscosity and modulus upon the incorporation of water-soluble polymers, specifically PBDT and PBDI. The addition of these polymers led to a noticeable increase in the modulus of the geopolymer resin, indicating enhanced mechanical properties.

The gel-like behavior observed in polymer-loaded samples suggests a potential for improved structural integrity and performance in geopolymer composites. The three-fold increase in viscosity with the incorporation of a 0.5 wt.% rigid polymer highlights the role of polymer concentration in modifying the resin’s rheological properties.

The TGA results confirmed the successful incorporation of PBDT and PBDI into the geopolymer composites. The thermal behavior of the samples, as indicated by the mass loss profiles, demonstrated the stability of the polymer-modified geopolymer materials up to high temperatures. The TGA analysis provided valuable insights into the thermal degradation behavior of the composites, which is essential for understanding their performance under different temperature conditions.

SEM analysis of the geopolymer plaques revealed detailed information about the microstructure and surface morphology of the composites. SEM images showed decreased microstructure porosity in samples containing 0.5 wt.% rigid polymer loadings, indicating improved densification and packing of the material. SEM results provided visual evidence of the impact of polymer incorporation on the microstructural features of the geopolymer composites, highlighting the potential for enhanced mechanical properties and performance.


The study demonstrates the potential of water-soluble polymers, such as PBDT and PBDI, in enhancing the rheological properties and microstructure of polymer-modified geopolymer glass ceramics. The findings provide valuable insights for developing advanced geopolymer composites with tailored properties for diverse materials science and engineering applications.

Further research and development in this area could lead to the design of advanced geopolymer materials with enhanced performance characteristics and broader industrial applications.

Journal Reference

Migliore, J.M., Hewitt, P., et al. (2024). Effect of Water-Soluble Polymers on the Rheology and Microstructure of Polymer-Modified Geopolymer Glass-Ceramics. Materials.
