An international team of researchers has found it can significantly boost an existing polymer’s ability to selectively remove carbon dioxide (CO2) out of gas mixtures by first submerging the material in water.
“Normally, improving the permeability of a gas through a material impairs the material’s selectivity,” says Rich Spontak, co-corresponding author of a paper on the work and Distinguished Professor of Chemical and Biomolecular Engineering and Professor of Materials Science and Engineering at North Carolina State University. “To explain this using CO2 as an example, the more easily gases can pass through a material, the less able the material usually is to remove CO2 from a gas mixture. It lets through the CO2, but it lets through other gases as well. There’s a real tradeoff when engineering polymers for use as gas-separation membranes.
Improved CO2 Permeability of Polymers
“What’s remarkable about our finding is that we were able to drastically improve the polymer’s CO2 permeability while also slightly improving its CO2 selectivity. And the process that led to this substantial improvement was related to transforming the microstructure of the membrane in low-cost and nontoxic fashion – we submerged the material in water.”
Polymer membranes that can filter out CO2 are desirable for use in a variety of applications, such as removing CO2 from natural gas and sequestering CO2 in order to limit emissions from industrial facilities.
Understanding the Morphology of The Material
The polymer at issue here is a thermoplastic elastomer that is recyclable, relatively tough, and has been shown to have desirable properties for a wide range of contemporary technologies. For this work, the researchers set out to see how the morphology of the material – how the molecular sequences comprising the polymer molecules are arranged relative to each other – affects its performance as a CO2-selective membrane.
The permeability of gases through polymers is frequently measured in Barrer units. When dry, the permeability of CO2 through the polymer examined in the paper is less than 30 Barrer. Previous work reported by members of the team had shown that inclusion of water vapor in the feed could improve CO2 permeability, boosting it to as high as 100-190 Barrer at relative humidity levels above 85%.
Increased Barrer Units with High Humidity
“With these new results, we’ve shown we can reach a permeability of almost 500 Barrer at 90% humidity,” says Liyuan Deng, Professor of Chemical Engineering at the Norwegian University of Science and Technology and co-corresponding author of the paper. “At the same time, the selectivity of CO2 relative to nitrogen (N2) increases to as high as ~60. For comparison, the best commercial polymer membranes that could be used for CO2 capture possess a permeability up to ~200 Barrer and a CO2/N2 selectivity up to ~50. It’s very important that both of these performance metrics are considered simultaneously to achieve competitive membranes.
“This work demonstrates the polymer’s potential for use in industrial gas separation and carbon capture technologies, with benefits for both manufacturing efficiency and efforts to mitigate global climate change. It also provides a previously unexplored and facile route by which to transform the morphology of a polymer membrane and achieve tremendous improvement in gas transport properties.”
