Toshiba Releases High Peak Output Current Photocouplers in Thin Packages for Driving IGBTs/MOSFETs Gates

Toshiba Electronic Devices & Storage Corporation ("Toshiba") has introduced two photocouplers, “TLP5705H” and “TLP5702H,” housed in a thin SO6L package, for use as insulated gate drivers for small to medium capacity IGBTs/MOSFETs. Volume shipments start today.

Toshiba: High peak output current photocouplers in thin packages for driving IGBTs/MOSFETs gates. Image Credit: Business Wire

TLP5705H is Toshiba’s first product to deliver a peak output current rating of ±5.0 A in a thin package (SO6L) only 2.3 mm (max) high. As a result, devices such as small to medium capacity inverters and servo amplifiers that use a buffer circuit for current amplification can now drive their IGBTs/MOSFETs directly from the photocoupler, without any need of the buffer circuit. This will contribute to parts reduction and set miniaturisation.

TLP5702H has a peak output current rating of ±2.5 A. An SO6L package that can be mounted on the land pattern of Toshiba’s conventional SDIP6 package [1], facilitating easy replacement of Toshiba’s current products [2]. The SO6L is thinner than SDIP6, which brings greater flexibility to component layouts on boards, and also allows it to be mounted on the back of a board or used where new circuit design imposes limits on available height.

Both photocouplers have a maximum operating temperature rating of 125 ºC (Ta=-40 to 125 ºC), making it easier to design and maintain temperature margins.

Toshiba’s line-up also includes TLP5702H(LF4) and TLP5705H(LF4), housed in an SO6L(LF4) package as a lead-forming option.

Notes:

[1] Package height: 4.25 mm (max)
[2] Current products: TLP700H in SDIP6 package

Applications

Industrial equipment

  • Industrial inverters, AC servo drives, PV inverters, UPS, etc.

Features

  • High peak output current rating (@Ta=-40 to 125 °C)
    IOP= ± 2.5 A (TLP5702H)
    IOP= ± 5.0 A (TLP5705H)
  • Thin SO6L package
  • High operating temperature rating: Topr (max)=125 °C
