Gold Nanorods Kit (Axial Diameter - 10 nm, Wavelength 700 - 808 nm)

The physical and chemical properties of Gold Nanorods are outlined in the following. Gold nanorods are shipped in 18MΩ DI water with < 0.1% ascorbic acid and < 0.1% CTAB surfactant capping agent.

Storage of Gold Nanorods

Gold nanorods should be stored at 4°C and should not be frozen. Do not store for longer than six months. CTAB may cause a cloudy appearance at low temperatures. To resuspend excess CTAB, warm to room temperature before use. Bottles need to be homogenized after long storage periods to resuspend any sedimentation, especially for larger nanorods.

Typical Characteristics (Specifications) of Gold Nanorods

The typical characteristics of gold nanorods are outlined in the following table.

Axial diameter = 10 nm
Axial peak SSRP = 512 nm

Part #

Longitudinal Size (nm)

Peak LSPR Wavelength (nm)

Wt. Conc (ug/ml)

LSPR Molar Ext. (M-1cm-1)

SSPR Molar Ext. (M-1cm-1)

79-6020

29

700

29.7

8.99E+08

2.25E+08

79-6025

35

750

33.4

9.40E+08

2.35E+08

79-6030

38

780

34.9

9.81E+08

2.45E+08

79-6035

41

8008

36.1

1.02E+09

2.55E+08




SPR = Surface plasmon resonance
LSPR = Longitudinal SPR peak
SSPR = Axial SPR peak
Shape monodispersity (% rods) > 95%
Size variation +/-10% (both dimensions)
Aspect ratio variation = Peak LSPR accuracy/96
All specs typical. May vary batch to batch.

Gold Nanorods Kit

Contains 25ml of each of the following:

79-6020 Gold Nanorods (Axial Diameter - 10nm) (Wavelength 700nm)
79-6025 Gold Nanorods (Axial Diameter - 10nm) (Wavelength 750nm)
79-6030 Gold Nanorods (Axial Diameter - 10nm) (Wavelength 780nm)
79-6035 Gold Nanorods (Axial Diameter - 10nm) (Wavelength 808nm)

This information has been sourced, reviewed and adapted from materials provided by Strem Chemicals.

For more information on this source, please visit Strem Chemicals.
