Single Point Diamond Turning (SPDT) is a precision machining process used to produce exceptionally flat, smooth, and optically precise surfaces. Although frequently associated with curved or aspheric surfaces, SPDT is also employed in machining flats for multiple advanced applications where both surface quality and dimensional accuracy are crucial.
Video Credit: AMETEK Precitech
Applications requiring precision flat surfaces include:
- Flat mirrors are used for high-performance optical systems (e.g., telescopes and laser systems).
- Reference flats for interferometric calibration.
- Infrared (IR) windows and domes produced from materials such as ZnSe, Ge, or CaF2.
- Wafer chucks and mask aligners that need ultra-flat surfaces.
Single Point Diamond Turning is uniquely suited for producing high-precision flat surfaces due to:
- Sub-nanometer surface roughness.
- High geometric accuracy (flatness, parallelism).
- The capability to machine hard-to-cut materials such as crystals, ceramics, and metals.
- Absence of subsurface damage, unlike grinding or polishing.
For over 30 years, Precitech has manufactured fly cutters and vertical turning lathes, and remains the only SPDT machine maker to offer a dedicated fly cutter: the Planoform 650 Ultra.
Transformative Advancements in Flat Surface Machining
Fly cutter technology surpasses conventional lathe systems and transforms flat surface manufacturing. Unlike traditional lathes, where the workpiece rotates, this arrangement rotates the cutting tool in a fly-cutting motion. This ensures flatter surfaces while avoiding common defects such as unintended cone or dish shapes.
Decades of continuous refinement have expanded machine capabilities to accommodate larger workpieces and provide greater flexibility. These enhancements boost efficiency, reduce costs through enhanced precision, and deliver superior product quality.
Vertical Turning Lathe: Precision and Versatility
Designed especially for heavy workpieces, the vertical turning lathe (VTL) is a major step forward in load management and precision engineering. By spanning a vertical rather than horizontal axis, the VTL simplifies handling and reduces the need for cumbersome equipment like cranes for loading and unloading workpieces.
This technology is vital in industries where precision in face patterning and smaller tolerances can significantly impact product performance and reliability. VTL technology enables finer finishes while pushing the boundaries of what is achievable in machining applications.
