MIRTEC to Exhibit 3D AOI and SPI Systems at SMTA Guadalajara

MIRTEC, “The Global Leader in Inspection Technology,” is pleased to announce plans to exhibit its award-winning MV-6 OMNI 3D AOI System and MS-11e 3D SPI Machine at the SMTA Guadalajara Expo & Tech Forum, scheduled to take place Nov. 14 - 15, 2018 at the Expo Guadalajara.

MIRTEC MV-6 OMNI

The award-winning MV-6 OMNI 3D AOI Machine is configured with MIRTEC’s exclusive OMNI-VISION® 3D Inspection Technology that combines the 15 Mega Pixel CoaXPress Camera Technology with MIRTEC’s revolutionary 8 Projection Digital Multi-Frequency Moiré 3D system in a newly designed cost-effective platform.  MIRTEC’s 15 Mega Pixel CoaXPress Vision System is a proprietary camera system designed and manufactured by MIRTEC for use with our complete product range of 3D inspection systems.  MIRTEC’s 8 Projection Digital Multi-Frequency Moiré Technology, provides true 3D inspection to yield precise height measurement data used to detect lifted component and lifted lead defects as well as solder volume post reflow.  Fully configured the MIRTEC MV-6 OMNI machines feature four (4) 10 Mega Pixel Side-View Cameras in addition to a 15 Mega Pixel Top-Down Camera.

MIRTEC’s award-winning MS-11e 3D SPI Machine is configured with an exclusive 15 Mega Pixel CoaXPress Camera System, providing enhanced image quality, superior accuracy and incredibly fast inspection rates.

The MS-11e uses Dual Projection Shadow Free Moiré Phase Shift Imaging Technology to inspect solder paste depositions on PCBs post screen print for insufficient solder, excessive solder, shape deformity, shift of deposition and bridging.  The MS-11e uses the same robust platform as MIRTEC’s MV-6 OMNI Series.

Source: http://mirteceurope.com/
