Hydroxypropyl Methyl Cellulose – Walocel HM FG

Wolff Cellulosics is the center of excellence for cellulose chemistry within Covestro. Its cellulose derivatives are used as additives for building materials and as raw materials for printing inks and surface coatings. High-purity cellulose derivatives are also used in food products, cosmetics and pharmaceutical products. At its state of the art pilot plant, Wolff Cellulosics develops new products and technologies for the production and processing of synthetic derivatives of the renewable raw material cellulose.

What is Walocel HM FG

Hydroxypropyl methylcellulose is manufactured from high purity cellulose in compliance with GMP and HACCP. In codes and regulations this product is also known as HPMC, E464 or modified cellulose.

Walocel® HM FG products meet all requirements of the Code of Federal Regulations of the Food and Drug Administration (FDA) Part 21 CFR 172 874, the FCC and the EU Directives for E 464 in their current version.

Walocel® HM FG are not subject to Regulations EC 1829 and 1830/2003 and can be regarded as free of genetically modified organisms.

Characteristics of Walocel HM FG

  • Controls the rheology of aqueous solutions
  • Gelling aqueous solutions ≈ 60° C
  • Compatibility with all other hydrocolloids
  • Good freeze/thaw stability
  • High water binding capacity
  • Dissolves at low temperatures
  • Replaces fat and protein in many applications
  • Effective in very acidic systems (>pH 1)
  • Has absolutely no odor or taste
  • Very stable in systems with high salt content

Walocel FM HG Description

Walocel® HM FG products are hydroxypropyl methylcellulose, which are defined by:

  • The degree of substitution (content of methoxy and hydroxypropoxy groups)
  • The degree of polymerization (length of the cellulose chain)

Product Range

Walocel®HM – Food Grades (FG)

Type*1

Substitution
Type

Viscosity*2
(mPas)

HM

3 PA

2910

2.4 – 3.6

HM

5 PA

2910

4.0 – 6.0

HM

6 PA

2910

4.8 – 7.2

HM

15 PA

2910

12.0 – 18.0

HM

50 PA

2910

40 – 60

HM

4000 PA

2910

3.200 – 4.800

HM

100 PA

2208

80 – 120

HM

1500 PA

2208

1.200 – 1.800

HM

4000 PA

2208

3.200 – 4.800

HM

15000 PA

2208

12.000 – 18.000

HM

100000 PA

2208

80.000 – 120.000

HM

50 PA

2906

40 – 60

HM

400 PA

2906

320 – 480

HM

4000 PA

2906

3.200 – 4.800

*1 Further viscosities available on request
*2 Viscosity measurement by capillary viscometry
HM = hydroxypropyl methylcellulose
100 = viscosity
P = powder
A = regulated product
FG = food grade

Walocel®HM – Etherification

Labelled Viscosity

Substitution Type

Methoxy Percentage

Hydroxy Propoxy Percentage

3 – 4000

2910

28 – 30

7 – 12

100 –100000

2208

19 – 24

4 – 12

50 – 4000

2906

27 – 30

4 – 7.5

Fields of Application

  • Extruded products
  • Deep fat fried products
  • Structured potato products
  • Dairy and non-dairy foams, whipped products/toppings (also purely vegetable)
  • Marinades, soups, sauces, dressings
  • Bakery goods (gluten-free, fat-reduced)
  • Bake-stable fillings for bakery products, creams and fruit preparations
  • Glazes and jelly coatings for bakery, meat, poultry and seafood
  • Coatings (pills, tablets, candies)
  • Food for diabetics

This information has been sourced, reviewed and adapted from materials provided by Covetro.

For more information on this source, please visit Covestro.
