BGI MARK-10 Force / Torque Gauge

The BGI Force / Torque Gauge is a unique product that is designed for working with interchangeable remote force and torque sensors. These sensors cover a variety of force measurement and torque measurement applications and are available in a broad range of capacities. No calibration or setup is required - simply plug and play.

Features:

  • Fully interchangeable force and torque BGI force/torque sensors with "personality" modules
  • Unlimited number of sensors possible due to unique design
  • Programmable default configuration for each sensor
  • RS-232, Mitutoyo and analog outputs
  • GCL - Gauge Control Language for full computer control
  • Averaging mode for average readings over time
  • External trigger for data capture and switch testing
  • Programmable dual set points with outputs
  • General purpose I/O for external device control
  • Programmable auto-shutoff
  • Selectable units of measurement
  • Push-button calibration
  • Battery or AC operation
  • Peak reading memory
  • Accuracy: ± 0.1% of full scale ±1 digit + sensor's accuracy
  • Sampling rate: 65 readings/sec
  • Battery life: 8 hours per charge
  • Weight: 0.9 lbs (0.4 kg)
  • Environmental requirements: 40°F - 100°F [5°C - 45°C], <96% humidity (non-condensating)
  • Warranty: 3 years
  • CE mark
