The XP3i is an ultra-durable, intrinsically safe digital test gauge offering accuracy levels of “0.05 % of reading,” “0.02 % of full scale,” or “0.05 % of full scale.” A single XP3i unit covers a wide pressure range and can replace several full-scale analog gauges. For applications that require pressure test recording, the optional DataLoggerXP upgrade unlocks extensive functionality and logging capabilities.
Now equipped with USB-C and Bluetooth connectivity, a free mobile app, and cloud-based software, users can easily share saved files with any colleague with internet access.
- Pressure ranges up to 15,000 psi
- Marine-grade housing resists corrosion (MIL-STD 810)
- Accuracy maintained from –20 to 50 °C (extended from the XP2i)
- Replaces five or more test gauges
- Fast pressure safety valve (PSV) mode
- Simple operation – No menu. No manual? No problem!
- Built-in calibration reminders and alerts
Bluetooth Connectivity Enables Users To:
- Safely connect in hazardous zones while maintaining intrinsic safety compliance
- Install the XP3i in hard-to-access areas and manage connections remotely from a secure location
- Avoid poor weather conditions by connecting from a climate-controlled workspace or vehicle
- No cable? Missing drivers? Damaged connector? Bluetooth eliminates all of these potential disruptions
With the Optional DataLoggerXP Upgrade
- Log over 200 million data points
- Support continuous data recording for more than a year
- Start or stop logging sessions directly from the gauge or your phone
- Download data via USB to a PC or wirelessly through Bluetooth and the mobile app
With the New CrystalControlWeb Cloud Software (Free)
- Upload stored data from your computer
- Upload wirelessly downloaded files from the app
- Share data with anyone in your organization
- Use a license key to grant access to team members
- Visualize data through customizable graphs
- Adjust graph properties like line color, axis limits, and test/run labels
- Configure XP3i settings remotely
- Export to spreadsheets or locked, tamper-evident PDF reports
