The Most Complete Image Analysis Solution

As one of the most powerful multipurpose image analysis tools currently available on the market, the Clemex Vision PE provides users with an exceptional range of digital functions.

As a fully integrated system, the Clemex Vision PE provides increased flexibility and efficiency for a number of analytical procedures, while also ensuring the production of highly accurate results. Some of the applications that the Clemex Vision PE has been successfully used include:

  • Cell count
  • Fiber length
  • Grain size
  • Graphite particles
  • Phase percentage
  • DAS
  • Layer thickness
  • Nodularity
  • Particle size
  • Phase area
  • Porosity
  • Shape analysis
  • Surface roughness
  • Unlimited custom analyses

Product Features

  • Various automation features
    • Dual magnification
    • Conditional instructions available for uncommon objects and those extending beyond the field of view
  • Provides a high throughput
  • Capable of capturing high-resolution images
  • Easily adaptable for any analysis requirements
  • Modular upgrades are easy to achieve and cost-effective
  • Compliant with numerous International Standards, some of which include:
    • ASTM A247
    • ASTM B46.1
    • ASTM B487
    • ASTM E1077
    • ASTM E112
    • ASTM E1245
    • ASTM E1268
    • ASTM E-45
    • ASTM E562
    • DIN17230
    • ISO 945
  • Aromatic exposure
  • Multi-layer grab
  • Automatic object separation
  • Automatic calibration
  • Image stitching
  • Improved image capturing system
    • Automated shading corrector provides even illumination in all captured images
    • Extended depth of field provides a perfectly focused image regardless of surface features
    • Multiple fields stitched together to form a single composite mosaic image
    • Relative gray threshold allows for objects present on a variable background to be accurately detected
  • Measurements can be created by the user or customized from pre-built options
  • Following image stitching, composite images can be analyzed and measured

The Most Complete Image Analysis Solution

The Most Complete Image Analysis Solution - Picture 1
The Most Complete Image Analysis Solution - Picture 2
The Most Complete Image Analysis Solution - Picture 3
The Most Complete Image Analysis Solution - Picture 4
Lumina brass at 200x. Color detection of phases within particles.
