UniSeal 2000TM is a closed-cell foam gasket and sealing material that exhibits resistance to UV radiation, ozone, and harsh environmental conditions. UniSeal is free from sulfur and is composed of low volatile condensable materials that are compatible with LED enclosures, including streetlight assemblies.
Additionally, UniSeal 2000TM is free from halogens and CFCs, offering outstanding sealing capabilities and anti-slip characteristics. It is especially effective for sealing against air, dust, and water in various sectors such as commercial, aerospace, automotive, and medical applications.
Benefits
- Withstands UV, Ozone, and harsh conditions
- Sulfur and plasticizer-free
- Provides superior anti-slip characteristics
Features
- Closed cell foam gasket
- Sealing and Anti-slip properties
- Free from halogen and CFC
Recommended Uses
- Gaskets provide sealing against water, air, dust, and moisture.
- Anti-slip pads and feet are included.
- Touch screen mounting is available.
- Battery cushioning is provided.
Technical Data
Typical Physical Properties
Source: Materials Direct
| Property (unit) |
Test Method |
UNISEAL 2000 |
| Total Thickness – includes compound and substrate (mm) |
Visual |
1–25 |
| Density (kg/m3) |
Visual |
100-185 |
| Flame Resistance |
FMVSS302 |
Self Extinguishing |
| Color |
Visual |
Black |
| Tensile Strength (kPa) |
ASTM D 412 |
<580 – 600 |
| Hardness (Shore 00) |
- |
40 |
Electrical and Mechanical Information
Source: Materials Direct
| Property (unit) |
Test Method |
UNISEAL 2000 |
| Water Adsorption – Max Weight Change (%) |
ADTM D 1056 |
<2 |
| Comp. Set ( 23 deg +/-2 deg C) (%) |
ASTM D 1056 |
<5 - 25 |
| Elongation (%) |
In House |
<200 – 250 |
| Continuous Temp. Range (°C) |
In House |
-40 to +85 |
| Maximum Temp. (°C) |
In House |
+110 |
Availability and Storage
Offered in custom die-cut preforms and shapes
Provided in diverse thicknesses to meet specific application needs
