IKA Mills - Tube Mill 100 Control

IKA’s Mill 100 Control is the world’s first patented tube mill. It is a batch mill with disposable grinding chambers, therefore eliminating the risk of cross-contamination and removing the additional workload of cleaning.

The Mill 100 Control can accommodate larger grinding chambers, up to a maximum volume of 100 ml (MT 100).

Both the grinding chamber and cover are transparent, allowing grinding tests to be observed at any time. The mill can be used for dry, brittle and hard materials and is able to accommodate a Mohs hardness of up to 5. It is especially suitable for grinding seeds such as wheat and corn. Additionally, the mill’s inbuilt safety mechanism ensures that it will only start when the hood is firmly closed.

Key Features

  • Adjustable timer, ranging from 5 seconds to 3 minutes
  • A USB interface allows the control and documentation of all parameters
  • Clear, multilingual OLED display that includes error codes
  • Optional interval operation
  • Numerous operating modes
  • Infinitely variable speed between 5,000 and 25,000 rpm
  • Adjustable safety time and sleep
  • Reproducible test results
  • Program and store test conditions as required
  • High quality touch keypad

Scope of Delivery (Grinding Chambers)

  • 1 x MT 40
  • 1 x MT 100
  • 1 x MMT 40

Technical Data

  • Circumferential speed max.: 65 m/s
  • Power-ON time: 3 min
  • Speed min.: 5000 rpm
  • Speed max.: 25000 rpm
  • Motor rating input: 100 W
  • Motor rating output: 80 W
  • Speed deviation: 2± %
  • Width: 180 mm
  • Height: 212 mm
  • Voltage: 220 - 240/100 - 120/100 V
  • Weight: 2.8 kg
  • Useable volume max.: 100 ml
  • Power input: 100 W
  • Depth: 300 mm
  • Feed hardness max.: 5 Mohs
  • Mill feed can be cooled in milling chamber with dry ice: yes
  • Operating principle: cutting/impact
  • Milling chamber, can be cooled with water: no
  • USB interface: yes
  • Analog output: no
  • Process type: batch
  • Mill feed can be cooled in milling chamber with liquid nitrogen: no
  • Protection class according to DIN EN 60529: IP 30
  • Frequency: 50/60 Hz
  • Feed grain size max.: 10 mm
  • Permissible relative humidity: 80%
  • Permissible ambient temperature max.: 40 °C
  • Permissible ambient temperature min.: 5 °C
  • RS 232 interface: no
